28-90507

Description
RF BNC Connector
CategoryThe connector
File Size79KB,1 Pages
ManufacturerVertiv
Download Datasheet Parametric View All

28-90507 Online Shopping

Suppliers Part Number Price MOQ In stock
28-90507 - - View Buy Now

28-90507 Overview

RF BNC Connector

28-90507 Parametric

Parameter NameAttribute value
MakerVertiv
Reach Compliance Codeunknown
ECCN codeEAR99
Connector typeRF BNC CONNECTOR
Manufacturer's serial number28-90507
Base Number Matches1
5
4
3
2
DRAWING NO.
1
28-90507
Description:
Part No:
CPFIUG782 75 BNC(M) 1PC TW RG59
28-90507
For RG 59/62 Cable
N/A
75 ohm
0~2 GHz
Body
Insulator
Contact
Zinc
Nickel plated
REVISIONS
01
OFFICIAL RELEASE
08-18-09
L
L
T
H
2009.09.0
8 09:38:55
+08'00'
D
Application:
Crimp Tool:
Impedance:
Frequency Range:
Material:
D
PP/ TPX
Brass Gold plated
Nickel plated
C
Coupling nut Zinc
RoHS Compliance: Yes
Technical Detail:
C
Refer to Emerson Document P/N 27-0000
CONTROLLED DOCUMENT
P/N
38.1 ±0.5
1.499 in ±.020
28-90507-CUST
Rev
01
Rel'd Date
SEP 14,09
B
23.0
.906 in
B
9.5
.374 in
HEX
REF
O
14.5
.570 in
CUSTOMER COPY
A
TOLERANCE UNLESS DRAWN BY
OTHERWISE SPECIFIED
LINDA.WU
DECIMALS
X
mm
CHECKED BY
DATE
08-18-09
DATE
08-18-09
08-18-09
Connectivity
Solutions
TITLE
A
DIM OUTLINE
X.X
X.XX
ANGLES
+
0.5
-
+
0.3
-
+
0.1
-
+
0.5
-
LINDA.WU
THOMAS
U/M
mm
APPROVED BY DATE
CPFIUG782 75 BNC (M) 1 PC TW RG59
SHEET
1 OF 1
DRAWING NO.
SIZE
v
THIS DRAWING WAS PRODUCED BY COMPUTER,
DO NOT SCALE DRAWING OR UPDATE MANUALLY.
28-90507
A
5
4
3
2
1
