2SD1658
TOSHIBA Transistor Silicon NPN Epitaxial Type (Darlington Power Transistor)
2SD1658
Micro Motor Drive, Hammer Drive Applications
Switching Applications
Power Amplifier Applications
Unit: mm
•
•
•
High DC current gain: h
FE
= 2000 (min) (V
CE
= 2 V, I
C
= 1 A)
Low saturation voltage: V
CE (sat)
= 1.5 V (max) (I
C
= 1 A, I
B
= 1 mA)
Zener diode included between collector and base
Maximum Ratings
(Ta = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power
dissipation
Junction temperature
Storage temperature range
Ta = 25°C
Tc = 25°C
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
60 ± 10
60 ± 10
8
2
0.5
1.5
10
150
−55
to 150
Unit
V
V
V
A
A
JEDEC
W
°C
°C
―
―
2-8H1A
JEITA
TOSHIBA
Weight: 0.82 g (typ.)
Equivalent Circuit
COLLECTOR
BASE
≈
4 kΩ
≈
800
Ω
EMITTER
1
2004-07-26
2SD1658
Electrical Characteristics
(Ta = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
DC current gain
Collector-emitter saturation voltage
Base-emitter saturation voltage
Transition frequency
Collector output capacitance
Turn-on time
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE
V
CE (sat)
V
BE (sat)
f
T
C
ob
t
on
I
B1
Test Condition
V
CB
= 45 V, I
E
= 0
V
EB
= 8 V, I
C
= 0
I
C
= 10 mA, I
B
= 0
V
CE
= 2 V, I
C
= 1 A
I
C
= 1 A, I
B
= 1 mA
I
C
= 1 A, I
B
= 1 mA
V
CE
= 2 V, I
C
= 0.5 A
V
CB
= 10 V, I
E
= 0, f = 1 MHz
Output
30
Ω
Min
―
―
50
2000
―
―
―
―
―
Typ.
―
―
60
―
―
―
100
20
0.4
Max
10
4
70
―
1.5
2.0
―
―
―
V
V
MHz
pF
Unit
µA
mA
V
20 µs
Input
I
B2
I
B1
I
B2
Switching time
Storage time
t
stg
―
4.0
―
µs
V
CC
= 30 V
Fall time
t
f
I
B1
=
−I
B2
= 1 mA, duty cycle
≤
1%
―
0.6
―
Marking
Lot No.
D1658
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
Part No. (or abbreviation code)
2
2004-07-26
2SD1658
