MAP30/40/42 AC-DC Series Data Sheet
Description
Features
• RoHS lead-solder-exempt compliant
• Universal input 85-264 VAC
• CE marked to Low Voltage Directive
• Input transient & ESD compliance to
EN61000-4-2/-3/-4
• Meets EN55022 conducted and radiated limits
• Greater than 311,000 Hours MTBF
• Remote sense (MAP30, MAP42)
Power-One’s MAP30/40/42 Series of power supplies combines low cost and universal input in a board-only power
solution to meet commercial and industrial requirements. Full international safety, EMI, and ESD compliance ensure
worldwide acceptance. All units bear the CE Mark.
Fixed frequency operation simplifies system level operation. The MAP30/40/42 Series is configured to the international
standard 3.00" x 5.00" footprint. Input and output connections are made via popular single-row Molex connectors.
Single output models feature wide-range output adjustability to meet a wide variety of standard and user-specific output
voltage requirements.
Single-Output Model Selection
MODEL
OUTPUT
VOLTAGE
ADJUSTMENT
RANGE
MAXIMUM OUTPUT
CURRENT
PEAK OUTPUT
CURRENT (NOTE 2)
LINE
REGULATION
LOAD
REGULATION
RIPPLE & NOISE
%p-p (NOTE 1)
INITIAL SETTING
ACCURACY
MAP30-1005
MAP42-1005
MAP42-1012
MAP42-1024
NOTES:
5V
5V
12V/15V
24V/28V
4.7V to 5.8V
4.7V to 5.8V
11.0V to 18.0V
23.0V to 29.0V
6A
8A
3.4/2.7A (Note 3)
1.7/1.4A (Note 3)
8A
11A
4.6/3.7A (Note 3)
2.3/1.9A (Note 3)
0.2%
0.2%
0.2%
0.2%
±1%
±1%
1%
1%
1%
1%
1%
1%
4.9V to 5.1V
4.9V to 5.1V
11.9V to 12.1V
23.8V to 24.2V
1) Maximum peak to peak noise expressed as a percentage of output voltage, 20 MHz bandwidth.
2) Peak ratings may be used as maximum output current with 100 Linear Feet per Minute (LFM) forced air cooling.
3) MAP42-1012 output currents are expressed as 12V/15V operation. MAP42-1024 output currents are expressed as 24V/28V operation.
Multiple-Output Model Selection
–
40W CONTINUOUS OUTPUT POWER
MODEL
OUTPUT
VOLTAGE
ADJUSTMENT
RANGE
OUTPUT
CURRENT
PEAK OUTPUT
CURRENT (NOTE 1)
LINE
REGULATION
LOAD
REGULATION
RIPPLE & NOISE
%p-p (NOTE 2)
INITIAL SETTING
ACCURACY
MAP40-3000
MAP40-3100
MAP40-3101
MAP40-3105
MAP40-3500
MAP40-3003
NOTES :
1)
2)
3)
4)
+5V
+12V
-12V
+5V
+12V
-12V
+5V
+24V
-12V
+5V
+12
-5V
+5V
+12V
-12V
+5V
+15V
-15V
4.75V to 5.50V
Fixed
Fixed
4.75V to 5.25V
Fixed
Fixed
4.75V to 5.25V
Fixed
Fixed
4.7V to 5.8V
Fixed
Fixed
4.7V to 5.8V
Fixed
Fixed
4.7V to 5.8V
Fixed
Fixed
3A
2A
0.3A
3A
2A
0.3A
3A
1A
0.3A
3A
2A
0.5A
5A
1A
0.3A
3A
1.5A
0.2A
5A
3.5A
0.5A
5A
3.5A
0.5A
5A
1.5A
0.5A
5A
3.5A
1.0A
6A
3.5A
0.5A
5A
3A
0.5A
0.2%
1%
1%
0.2%
1%
1%
0.2%
1%
1%
0.2%
1%
1%
0.2%
1%
1%
0.2%
1%
1%
2%
3.5% (Note 3)
2% (Note 4)
2%
3.5% (Note 3)
2%
2%
3.5% (Note 3)
2%
2%
3.5% (Note 3)
2%
2%
3.5% (Note 3)
2%
2%
3.5% (Note 3)
2% (Note 4)
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
1%
4.9V to 5.1V
11.5V to 12.5V
-11.4V to -12.6V
4.9V to 5.1V
11.5V to 12.5V
-11.4V to -12.6V
4.9V to 5.1V
23.0V to 25.0V
-11.5V to -12.5V
4.9V to 5.1V
11.5V to 12.5V
-4.75V to -5.25V
4.9V to 5.1V
11.5V to 12.5V
-11.4V to -12.6V
4.9V to 5.1V
14.7V to 15.3V
-14.3V to -15.7V
Peak loads for 30 seconds or less are acceptable, (10% duty cycle max.).
Maximum peak-to-peak noise expressed as a percentage of output voltage, 20 MHz bandwidth.
Quasi regulated output. See Regulation Curves for more information.
Requires a minimum load of 0.5A on V1 or 0.3A on V2.
REV. SEP 07, 2004 revised to JUN 19, 2006
Page 1 of 5
www.power-one.com
MAP30/40/42 AC-DC Series Data Sheet
Input Specifications
PARAMETER
CONDITIONS/DESCRIPTION
MIN
NOM
MAX
UNITS
Input Voltage - AC
Input Frequency
Brown Out Protection
Hold-up Time
Input Current
Input Protection
Inrush Surge Current
Operating Frequency
Continuous input range.
MAP42
MAP30, MAP40
AC input.
Lowest AC input voltage that regulation is maintained with full rated loads.
Nominal AC Input Voltage (115VAC), full rated load.
90 VAC (40W load).
Non-user serviceable internally located AC input line fuse.
Internally limited by thermistor. Vin = 264VAC (one cycle). 25° C.
Switching frequency of power supply (fixed frequency).
85
90
47
85
15
264
264
63
VAC
Hz
VAC
ms
A
RMS
A
PK
kHz
1.2
38
23
25
30
Output Specifications
PARAMETER
CONDITIONS/DESCRIPTION
MIN
NOM
MAX
UNITS
Efficiency
Minimum Loads
Ripple and Noise
Output Power
Overshoot / Undershoot
Regulation
Transient Response
Turn-on Delay
Turn-on Rise Time
Full load, 120VAC.
Single output models; MAP30, MAP42.
All multiple output models, see regulation graphs.
Full load, 20 MHz bandwidth.
Multiple output models with convection cooling.
Output voltage overshoot/undershoot at turn-on, V1.
Varies by output, total regulation includes: Line changes from 90-132
VAC or 175-264, changes in load starting at 20% load and changing
to 100% load.
Recovery time, to within 1% of initial set point due to a 50-100%
load change, 4% max. deviation. (Main output only of multiple output units).
Time required for initial output voltage stabilization.
Time required for output voltage to rise from 10% to 90%.
70
0.0
%
Amps
See Model Selection Chart.
40
Watts
1
%
See regulation graphs.
500
1
20
2
μs
Sec
ms
Interface Signals and Internal Protection
PARAMETER
CONDITIONS/DESCRIPTION
MIN
NOM
MAX
UNITS
Overvoltage
Protection
Overload
Protection
Remote Sense
MAP30-1005, MAP42-1005
MAP42-1012
MAP42-1024
Main output only of multiple output units.
Fully protected against output overload and short circuit. Automatic
recovery upon removal of overload condition.
Total cable drop, single output models only.
5.8
20.0
32.0
5.8
130
6.8
22.0
37.0
6.8
V
%
250
mV
Safety, Regulatory, and EMI Specifications
PARAMETER
CONDITIONS/DESCRIPTION
MIN
NOM
MAX
UNITS
Agency Approvals
Dielectric Withstand
Voltage
Electromagnetic
Interference
Input Transient
Protection
Insulation Resistance
Leakage Current
NOTES:
UL60950.
CSA 22.2 No. 60950.
EN60950 (TUV).
Input to output.
FCC CFR title 47 part 15 sub-part B - conducted.
EN55022 / CISPR 22 conducted (Note 1).
EN55022 / CISPR 22 radiated (Note 2).
EN61000-4-5 Level 3
Input to output.
Per EN60950, 264VAC
Approved.
2600
B
B
B
Line to Line
Line to Ground
1
2
7
500
750
VDC
Class
kV
MΩ
μA
MAP42, MAP40-3100, 3001, 3105, 3500
MAP30-1005, MAP40-3000, MAP40-3003
1) MAP30-1005, MAP40-3000, MAP40-3003 meet Class A.
2) MAP40-3000, MAP40-3003, MAP3500 meet Class A.
REV. SEP 07, 2004 revised to JUN 19, 2006
Page 2 of 5
www.power-one.com
MAP30/40/42 AC-DC Series Data Sheet
Environmental Specifications
PARAMETER
CONDITIONS/DESCRIPTION
MIN
NOM
MAX
UNITS
Altitude
Operating Temperature
Storage Temperature
Temperature Coefficient
Relative Humidity
Shock
Vibration
Operating.
Non-operating.
Derate linearly above 50°C by 2.5%
per °C to a maximum temperature of 70°C.
0°C to 70°C (after 15 minute warm-up).
Non-condensing.
Operating, peak acceleration.
Random vibration, 10Hz to 2kHz, 3 axis.
At 100% load:
At 50% load:
0
0
-40
±0.02
5
10k
40k
50
70
85
±0.03
95
20
6
ASL Ft.
ASL Ft.
°C
°C
°C
%/°C
%RH
G
G
RMS
NUCLEAR AND MEDICAL APPLICATIONS - Power-One products are not designed, intended for use in, or authorized for use as critical components
in life support systems, equipment used in hazardous environments, or nuclear control systems without the express written consent of the respective
divisional president of Power-One, Inc.
TECHNICAL REVISIONS - The appearance of products, including safety agency certifications pictured on labels, may change depending on the date
manufactured. Specifications are subject to change without notice.
REV. SEP 07, 2004 revised to JUN 19, 2006
Page 3 of 5
www.power-one.com
MAP30/40/42 AC-DC Series Data Sheet
MAP40-3500 TYPICAL QUASI REGULATION
PERFORMANCE FOR +12V OUTPUT
14.25
13.75
12V OUTPUT VOLTAGE
13.25
12.75
+5V @ 5.0 Amps
12.25
+5V @ 3.0 Amps
+5V @ 1.0 Amps
+5V @ 0 Amps
11.25
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
11.75
12V OUTPUT CURRENT
MAP40-3000/3100/3105 TYPICAL QUASI REGULATION
PERFORMANCE FOR +12V OUTPUT
13.5
12V OUTPUT VOLTAGE
13.0
12.5
12.0
+5V @ 3.0 Amps
11.5
+5V @ 1.8 Amps
+5V @ 0.6 Amps
+5V @ 0 Amps
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
11.0
12V OUTPUT CURRENT
MAP40-3003 TYPICAL QUASI REGULATION
PERFORMANCE FOR +15V OUTPUT
17.0
16.5
16.0
15V OUTPUT VOLTAGE
15.5
15.0
14.5
14.0
13.5
0
0.15
0.3
0.45
0.6
0.75
0.9
1.05
1.2
1.35
1.5
+5V @ 3.0 Amps
+5V @ 1.8 Amps
+5V @ 0.6 Amps
+5V @ 0 Amps
15V OUTPUT CURRENT
REV. SEP 07, 2004 revised to JUN 19, 2006
Page 4 of 5
www.power-one.com
MAP30/40/42 AC-DC Series Data Sheet
OVERALL SIZE: 5.00" x 3.00" x (see table) (127.0mm x 76.2mm x see table)
WEIGHT: 0.6 lb (0.26 kg)
J1
NEUTRAL
PIN 1
MAP30 J2
PIN 7
N/C
V1
V1
GND
GND
+Sense
-Sense
MAP40 J2
PIN 6
V2
V1
V1
GND
GND
V3
MAP42 J2
PIN 6
V1
V1
GND
GND
+Sense
-Sense
LINE
PIN 2
J3
SAFETY EARTH GROUND
(0.250" x 0.032" FASTON)
PIN 1
PIN 1
PIN 1
J1/J2 MATES WITH MOLEX (SERIES 2139 or SERIES 41695) .156" (4mm)
CENTER CRIMP TERMINAL HOUSING OR EQUIVALENT
MAP30/40/42 SERIES HEIGHT
Single Output Models
Model
MAP30-1005
MAP42-1005
MAP42-1012
MAP42-1024
Height
1.16" (29.5)
1.25" (31.8)
1.25" (31.8)
1.25" (31.8)
Multiple Output Models
Model
MAP40-3000
MAP40-3003
MAP40-3100
MAP40-3101
MAP40-3105
MAP40-3500
Height
1.16" (29.5)
1.16" (29.5)
1.25" (31.8)
1.25" (31.8)
1.25" (31.8)
1.60" (40.6)
www.power-one.com
REV. SEP 07, 2004 revised to JUN 19, 2006
Page 5 of 5
