X1G004171001015 datasheet, PDF

Datasheet> All Categories > oscillator> X1G004171001015

X1G004171001015: DescriptionCMOS Output Clock Oscillator,; Categoryoscillator; File Size266KB，5 Pages; ManufacturerSeiko Epson Corporation; Environmental Compliance

Download Datasheet Parametric Compare View All

X1G004171001015 Overview

CMOS Output Clock Oscillator,

X1G004171001015 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Seiko Epson Corporation
package instruction	LCC4,.08X.1,66/51
Reach Compliance Code	unknown
Other features	STANDBY; ENABLE/DISABLE FUNCTION
maximum descent time	3.5 ns
Frequency Adjustment - Mechanical	NO
frequency stability	50%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	4
Nominal operating frequency	4.096 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	CMOS
Output load	15 pF
Encapsulate equivalent code	LCC4,.08X.1,66/51
physical size	2.5mm x 2.0mm x 0.8mm
longest rise time	3.5 ns
Maximum slew rate	1.8 mA
Maximum supply voltage	3.6 V
Minimum supply voltage	1.6 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au)
Base Number Matches	1

Preview

Download Datasheet

View All

Clock OSC

SG-210STF

SG-210STF 4.096000 MHz L

Product name

Product Number / Ordering code

X1G0041710010xx

Please refer to the 8.Packing information about xx (last 2 digits)

Output waveform CMOS

Pb free / Complies with EU RoHS directive

Reference weight Typ. 12 mg

1.Absolute maximum ratings

Parameter

Symbol

Maximum supply voltage

Storage temperature

Input voltage

Min.

-0.3

-40

-0.3

Typ.

Max.

+125

Vcc+0.3

Unit

ºC

Conditions / Remarks

Storage as single product

ST terminal

Vcc-GND

T_stg

Vin

2.Specifications(characteristics)

Parameter

Symbol

Output frequency

Supply voltage

Operating temperature

Frequency tolerance

Current consumption

Stand-by current

Symmetry

Output voltage

Output load condition

Input voltage

Min.

1.6

-40

-50

Vcc-0.4

0.8Vcc

-3

Typ.

4.096000

2.4

2.3

2.5

Max.

3.6

+85

1.8

2.7

0.4

0.2Vcc

3.5

Unit

MHz

ºC

x10

-6

µA

Conditions / Remarks

T_use

No load condition Vcc = 3.6V

Vcc = 3.6V , ST = GND

50% Vcc Level L_CMOS=<15pF

Vcc

T_use

f_tol

Icc

I_std

SYM

L_CMOS

t_str

RMS

p-p

acc

CMOS Load

ST terminal

Vcc1.8V±10% : 0.2Vcc to 0.8Vcc Level,

L_CMOS=15pF

Vcc1.8V±10% : 0.2Vcc to 0.8Vcc Level,

L_CMOS=15pF

t = 0 at 0.9Vcc

Deterministic Jitter Vcc=3.3V

Random Jitter Vcc=3.3V

δ(RMS of total distribution) Vcc=3.3V

Peak to Peak Vcc=3.3V

Accumulated Jitter(δ) n=2 to 50000

cycles

Rise time

Fall time

Start-up time

Jitter

dBc/Hz

x10

-6

Phase jitter

Phase noise

L(f)

@+25ºC first year

Frequency aging

f_age

1 Page
