345705-2 Product Details
Live Product Chat
DIP Sockets
Always ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
345705-2
T E I nternal N umber: 3 4 5 7 0 5 - 2
Product Highlights:
l
Socket Style = Standard
l
Through Hole C ontact Termination Type
l
2.54 mm C enterline
l
Row-to-Row Spacing = 7.62 mm
l
20 Positions
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Socket Style
= Standard
l
Number of Positions
= 20
l
Profile = Standard
l
Frame Style
= C losed
l
Leg Style
= Straight
Electrical Characteristics:
l
Insulation Resistance (M?) = 10,000
l
C ontact Resistance (m?) = 30
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.84 [0.112]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
C enterline (mm [in])
= 2.54 [0.100]
l
Row-to-Row Spacing (mm [in])
= 7.62 [0.300]
l
Mount Style
= Vertical
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Base Material
= Beryllium C opper
l
C ontact Plating, Mating Area, Material
= Gold (20)
l
C ontact Style
= Screw Machine
l
Mating C ontact Type
= Inner Spring
Housing Related Features:
l
Housing Material = Thermoplastic - GF
Configuration Related Features:
l
Height Above PC Board (mm [in])
= 2.80 [0.110]
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
RoHS/ELV C ompliance History = Always was ELV compliant
Conditions for Usage:
l
Temperature Range (?C ) = 105
Packaging Related Features:
l
Packaging Method
= Tube
Other:
l
Brand = AMP
