PDB-C201
Blue Enhanced Bi-Cell Silicon Photodiode
PACKAGE DIMENSIONS INCH [mm]
PACKAGE DIMENSIONS INCH [mm]
.168 [4.27]
.075 [1.91]
3X Ø.018 [0.46]
1
Ø.330 [8.38]
Ø.320 [8.13]
Ø.200 [5.08]
PIN CIRCLE
2
45°
72°
VIEWING
Ø.255 [6.48] ANGLE
Ø.245 [6.22]
.010 [0.25] MAX
GLASS ABOVE CAP TOP EDGE
Ø .362 [9.19]
Ø .357 [9.07]
3X .50 [12.7] MIN
CELL 1
2
CELL 2
3
1
3
CHIP DIMENSIONS INCH [mm]
ANODE CELL #1
CASE GROUND &
COMMON CATHODE
ANODE CELL #2
CHIP DIMENSIONS INCH [mm]
1
2
.004 [0.10] GAP
2X .100 [2.54] ACTIVE AREA
2X .050 [1.27] ACTIVE AREA
.150 [3.81] SQUARE
TO-46 PACKAGE
SCHEMATIC
TO-5 PACKAGE
FEATURES
•
•
•
•
Low capacitance
Blue enhanced
High speed
Low dark current
DESCRIPTION
The
PDB-C201
is a blue enhanced Bi-Cell silicon
photodiode used for nulling, centering, or measuring
small positional changes packaged in a hermetic
TO-5 metal package.
0.80
Responsivity (A/W)
0.70
0.60
0.50
0.40
0.30
0.20
0.10
0.00
250
300
350
APPLICATIONS
• Emitter Alignment
• Position sensing
• Medical and Industrial
ABSOLUTE MAXIMUM RATING
(TA)= 23°C UNLESS OTHERWISE NOTED
SYMBOL
V
BR
T
STG
T
O
T
S
PARAMETER
Reverse Voltage
Storage Temperature
Operating Temperature
Soldering Temperature*
-55
-40
MIN
MAX
100
+150
+125
+240
UNITS
V
°C
°C
°C
SPECTRAL RESPONSE
400
450
500
550
600
650
700
750
800
850
900
950
1000
1050
1100
Wavelength (nm)
ELECTRO-OPTICAL CHARACTERISTICS RATING
(TA)= 23°C UNLESS OTHERWISE NOTED
SYMBOL
I
SC
I
D
R
SH
C
J
lrange
V
BR
NEP
t
r
CHARACTERISTIC
Short Circuit Current
Dark Current
Shunt Resistance
Junction Capacitance
Spectral Application Range
Breakdown Voltage
Noise Equivalent Power
Response Time**
TEST CONDITIONS
H = 100 fc, 2850 K
V
R
= 5V
V
R
= 10 mV
V
R
=10 V,
f
= 1 MHz
Spot Scan
I = 10
μA
V
R
= 0V @
l=Peak
RL = 50
Ω,V
R
= 0 V
RL = 50
Ω,V
R
= 10 V
MIN
50
250
350
50
TYP
75
0.5
500
15
75
1X10
-14
190
13
MAX
2.0
UNITS
µA
nA
MΩ
pF
nm
V
W/
√
Hz
nS
1100
**Response time of 10% to 90% is specified at 660nm wavelength light.
Information in this technical datasheet is believed to be correct and reliable. However, no responsibility is assumed for possible inaccuracies or omission. Specifications are
subject to change without notice.
www.lasercomponents.com
Issue:
08/06
/ V1 / HW /
api/si-pin/bi-cells/ pdb-c201.pdf
Germany and other countries: LASER COMPONENTS GmbH, Phone: +49 8142 2864 0, Fax: +49 8142 2864 11, info@lasercomponents.com
Great Britain: LASER COMPONENTS (UK) Ltd., Phone: +44 1245 491 499, Fax: +44 1245 491 801, info@lasercomponents.co.uk
1150
* 1/16 inch from case for 3 seconds max.
