Laser
Diodes
Laser Module
LC-LMD-650-01
Ø 4 mm, 650 nm Laser Module
Features
1. APC (auto power control) IC inside
2. Low current consumption of the APC circuit
3. Much smaller LD module
4. Surge current protection
5. High quality lens for output beam
Part No. Indications
L C-LMD
650
01
XX
Output Power:
01- <1 mW
03- <3 mW
A
Part No. with 100 mm Flying Leads (1 mW Version only)
LC -LMD
6 50
01
01
A
C
Absolute Maximum Ratings
Item
Power supply voltage
Laser Module optical output power
Operation temperature
Storage temperature
1
Symbol
V
CC
P
o
T
opr
T
stg
Rating
3.3
<3
0 ~ 40
0 ~ 60
Unit
V
mW
°C
°C
Germany & Other Countries
Laser Components GmbH
Tel: +49 8142 2864 – 0
Fax: +49 8142 2864 – 11
info@lasercomponents.com
www.lasercomponents.com
France
Laser Components S.A.S.
Tel: +33 1 39 59 52 25
Fax: +33 1 39 59 53 50
info@lasercomponents.fr
www.lasercomponents.fr
United Kingdom
Laser Components (UK) Ltd.
Tel: +44 1245 491 499
Fax: +44 1245 491 801
info@lasercomponents.co.uk
www.lasercomponents.co.uk
Nordic Countries
Laser Components Nordic AB
Tel: +46 31 703 71 73
Fax: +46 31 703 71 01
info@lasercomponents.se
www.lasercomponents.se
USA
Laser Components USA, Inc.
Tel: +1 603 821 – 7040
Fax: +1 603 821 – 7041
info@laser-components.com
www.laser-components.com
Laser
Diodes
Laser Module
LC-LMD-650-01
Electrical and Optical Characteristics (T
C
= 25 °C)
Item
Wavelength
Output power
P
out
Symbol
l
01
03
l
op
V
op
Min.
645
-
2.2
-
2.5
Typ.
655
0.6
-
15
-
Max
660
0.9
3.0
25
3.3
< 20 mm
2.0 mrad
>10000 hrs
Unit
nm
mW
mW
mA
Volt
Condition
P
o
= < 3 mW
V
cc
= 3 V
V
cc
= 3 V
P
o
= 3 mW
V
cc
= 3 V
Operation current
Operation voltage
Laser Beam spot size at 10 m
Divergence angle
Mean time to failure (MTTF) 2 mW 25 °C
Outline Dimensions (Units: mm)
8.5 ± 0.05
Ø 4 +0
– 0.02
Aperture size: 1.3 mm
Pin Assignment
08/15 / V6 / HW / divers-opto/module/lc-lmd-650-01
Pin 1:
Pin 2:
Pin 3:
V
cc
GND
NC
A type:
Heat sink stand (-)
2
