Ordering number : ENN7680
SVC272
Silicon Diffused Junction Type Varactor Diode
SVC272
FM Receiver Electronic Tuning Applications
Features
•
Package Dimensions
unit : mm
1326
[SVC272]
0.25
•
•
•
Twin type varactor diode with good large-signal
characteristics for FM receiver electronic tuning
use.
Small package permits SVC272-applied sets to
be compact and slim.
Can be also provieded in tape reel package thereby
automatic insertion is supported.
High Quality Factor.
0.3
3
0.15
2.1
1.6
Electrical Connection
3
1 : Anode
2 : Anode
3 : Cathode
Top view
1
2
0.25
0.65
2.0
(Bottom view)
0.07
2
1
3
1 : Anode
2 : Anode
3 : Cathode
1
2
SANYO : MCPH3
(Top view)
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Reverse Voltage
Junction Temperature
Storage Temperature
Symbol
VR
Tj
Tstg
Conditions
Ratings
16
125
--55 to +125
Unit
V
°C
°C
Electrical Characteristics
at Ta=25°C
Parameter
Breakdown Voltage
Reverse Current
Interterminal Capacitance
*
Quality Factor
Capacitance Ratio
Matching Tolerance
Symbol
V(BR)R
IR
C2.0V
C8.0V
Q
CR
∆Cm
IR=10µA
VR=10V
VR=2.0V, f=1MHz
VR=8.0V, f=1MHz
VR=2.0V, f=100MHz
C2.0V / C8.0V
VR=2.0V, 8.0, f=1MHz (C max-C min) / C min!100
Conditions
Ratings
min
14
50
44.91
14.07
150
2.3
3.0
%
49.82
18.55
typ
max
Unit
V
nA
pF
pF
Note)* : Capacitance value per each diode.
Marking : V2
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
71504 VB TS IM TA-100827 No.7680-1/3
0.85
SVC272
Specifications of any and all SANYO products described or contained herein stipulate the performance,
characteristics, and functions of the described products in the independent state, and are not guarantees
of the performance, characteristics, and functions of the described products as mounted in the customer’s
products or equipment. To verify symptoms and states that cannot be evaluated in an independent device,
the customer should always evaluate and test devices mounted in the customer’s products or equipment.
SANYO Electric Co., Ltd. strives to supply high-quality high-reliability products. However, any and all
semiconductor products fail with some probability. It is possible that these probabilistic failures could
give rise to accidents or events that could endanger human lives, that could give rise to smoke or fire,
or that could cause damage to other property. When designing equipment, adopt safety measures so
that these kinds of accidents or events cannot occur. Such measures include but are not limited to protective
circuits and error prevention circuits for safe design, redundant design, and structural design.
In the event that any or all SANYO products(including technical data,services) described or
contained herein are controlled under any of applicable local export control laws and regulations,
such products must not be exported without obtaining the export license from the authorities
concerned in accordance with the above law.
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording, or any information storage or retrieval system,
or otherwise, without the prior written permission of SANYO Electric Co., Ltd.
Any and all information described or contained herein are subject to change without notice due to
product/technology improvement, etc. When designing equipment, refer to the "Delivery Specification"
for the SANYO product that you intend to use.
Information (including circuit diagrams and circuit parameters) herein is for example only ; it is not
guaranteed for volume production. SANYO believes information herein is accurate and reliable, but
no guarantees are made or implied regarding its use or any infringements of intellectual property rights
or other rights of third parties.
This catalog provides information as of July, 2004. Specifications and information herein are subject
to change without notice.
PS No.7680-3/3
