Semiconductor
DN500F
NPN Silicon Transistor
Description
•
Extremely low collector-to-emitter saturation voltage
( V
CE(SAT)
=0.2V Typ. @I
C
/I
B
=3A/150
㎃)
•
Suitable for low voltage large current drivers
•
Excellent h
FE
Linearity
•
Complementary pair with DP500F
•
Switching Application
Ordering Information
Type NO.
DN500F
Marking
N5
Package Code
SOT-89
Outline Dimensions
3.70~4.30
1.50 Typ.
2.40~2.70
1.20 Max.
unit :
mm
3
4.40~4.70
1.87 Max.
4
2
0.58 Max.
1
0.48 Max.
1.40~1.70
1.50 Typ.
0.10 Max.
KST-8012-003
0.46 Max.
PIN Connections
1. Base
2. Collector
3. Emitter
1
DN500F
Absolute maximum ratings
Characteristic
Collector-Base voltage
Collector-Emitter voltage
Emitter-Base voltage
Collector current
Collector power dissipation
Junction temperature
Storage temperature
(Ta=25°C)
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
P
C
*
Ratings
15
12
5
5
0.5
2
150
-55~150
Unit
V
V
V
A
W
°C
°C
T
J
T
stg
* : When mounted on 40×40×0.8
㎜
ceramic substate
Electrical Characteristics
Characteristic
Collector-Base breakdown voltage
Collector-Emitter breakdown voltage
Emitter-Base breakdown voltage
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-Emitter on voltage
Base-Emitter on voltage
Transition frequency
Collector output capacitance
(Ta=25°C)
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
h
FE1
h
FE2
V
CE(sat1)
V
BE(sat)
f
T
C
ob
Test Condition
I
C
=50
㎂
, I
E
=0
I
C
=1
㎃
, I
B
=0
I
E
=50
㎂
, I
C
=0
V
CB
=15V, I
E
=0
V
EB
=4V, I
C
=0
V
CE
=1V, I
C
=100
㎃
V
CE
=1V, I
C
=3A
I
C
=3A, I
B
=150
㎃
I
C
=3A, I
B
=150
㎃
V
CB
=5V, I
C
=500
㎃
V
CB
=10V, I
E
=0, f=1
㎒
Min. Typ. Max.
15
12
5
-
-
120
40
-
-
-
-
-
-
-
-
-
-
-
-
-
150
-
-
-
-
0.1
0.1
700
-
0.3
1.2
-
50
Unit
V
V
V
㎂
㎂
-
-
V
V
㎒
㎊
KST-8012-003
2
DN500F
The AUK Corp. products are intended for the use as components in general electronic
equipment (Office and communication equipment, measuring equipment, home
appliance, etc.).
Please make sure that you consult with us before you use these AUK Corp. products
in equipments which require high quality and / or reliability, and in equipments which
could have major impact to the welfare of human life(atomic energy control, airplane,
spaceship, transportation, combustion control, all types of safety device, etc.). AUK
Corp. cannot accept liability to any damage which may occur in case these AUK Corp.
products were used in the mentioned equipments without prior consultation with AUK
Corp..
Specifications mentioned in this publication are subject to change without notice.
KST-8012-003
4
