SBC338
Absolute maximum ratings
Characteristic
Collector-Base voltage
Collector-Emitter voltage
Emitter-Base voltage
Collector current
Collector dissipation
Junction temperature
Storage temperature
(Ta=25°C)
°
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
j
T
stg
Ratings
30
25
5
800
625
150
-55~150
Unit
V
V
V
mA
mW
°C
°C
Electrical Characteristics
Characteristic
Collector-Emitter breakdown voltage
Base-Emitter turn on voltage
Collector-Emitter saturation voltage
Collector cut-off current
DC current gain
Transition frequency
Collector output capacitance
(Ta=25°C)
°
Symbol
BV
CEO
V
BE(ON)
V
CE(sat)
I
CBO
h
FE
*
f
T
C
ob
Test Condition
I
C
=1mA, I
B
=0
V
CE
=1V,
I
C
=300mA
I
C
=500mA, I
B
=50mA
V
CB
=30V, I
E
=0
V
CE
=1V, I
C
=100mA
V
CB
=5V, I
C
=10mA
V
CB
=10V, I
E
=0, f=1MHz
Min. Typ. Max.
25
-
-
-
100
-
-
-
-
-
-
-
100
16
-
1.2
700
100
630
-
-
Unit
V
V
mV
nA
-
MHz
pF
* : h
FE
rank /
16(A) : 100 ~ 250,
25(B) : 160 ~ 400,
40(C) : 250 ~ 630
