Rh
Semiconductor
SDS511G
Switching Diode
Features
•
•
•
•
Ultra high speed switching application
Low forward voltage : V
F
=0.9V(Typ.)
Fast reverse recovery time : t
rr
=1.6
㎱
(Typ.)
Small total capacitance : C
T
=2.2
㎊
(Typ.)
Ordering Information
Type No.
SDS511G
Marking
1G
Package Code
SOD-123
Outline Dimensions
unit :
mm
3.30~3.70
0.99 Max.
2.60~2.80
1.50~1.70
CATHODE MARK
0.70~0.80
KSD-D6B004-000
0.22 Max.
PIN Connections
1. Anode
2. Cathode
1
SDS511G
Absolute Maximum Ratings
Characteristic
Peak reverse voltage
Reverse voltage
Peak forward current
Average forward current
Peak forward surge current
(Non-repetitive 60Hz sine wave)
Power dissipation (*Note1)
Junction temperature
Storage temperature range
*Note1: Device mounted on glass epoxy board
(
Ta=25°C)
Symbol
V
RM
V
R
I
FM
I
O
I
FSM
P
D
T
j
T
stg
Rating
85
80
300
100
2
350
150
-55 ~ 150
Unit
V
V
㎃
㎃
A
½
°C
°C
Electrical Characteristics
Characteristic
Forward voltage
(
Ta=25°C)
Test Condition
I
F
=1
㎃
I
F
=10
㎃
I
F
=100
㎃
V
R
=80V
V
R
=0, f=1
㎒
I
F
=10
㎃
(Fig. 5)
Symbol
V
F(1)
V
F(2)
V
F(3)
I
R
C
T
Min. Typ. Max.
-
-
-
-
-
-
0.6
0.7
0.9
-
2.2
1.6
-
-
1.2
0.5
4.0
4.0
Unit
V
Reverse current
Total capacitance
Reverse recovery time
㎂
㎊
㎱
t
rr
※
Recommend PCB solder land (Unit : mm)
KSD-D6B004-000
2
SDS511G
