3B104P Product Details
Live Product Chat
Product Photo
NEMA Terminal Blocks
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3B104P
(4-1437381-1)
T E I nternal N umber: 4 - 1 4 3 7 3 8 1 - 1
Product Highlights:
l
B100 Series Block Series
l
Terminal Block (one piece)
l
Block Type = Shorting
l
Heavy Industrial Application
l
C ontact Type = Steel Strap Screw
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
BUC HANAN TERMINAL BLOC KS C ATALOG - NEMA TERMINAL BLOC KS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version P099)
l
3D Model
(IGES, Version P099)
l
3D Model
(STEP, Version P099)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Terminal Block (one piece)
l
Number of C ircuits
= 4
l
Screw Size = 10-32 Binding Head
Electrical Characteristics:
l
Voltage Rating (VAC ) = 600
Body Related Features:
l
Block Series
= B100 Series
l
Block Type = Shorting
l
Mount Style = Direct Mount (Flat Base)
l
Wire Range (Solid and Stranded)[MC M] (AWG)
= 18-8
l
Blown Fuse Indicator
= Without
l
Blown Fuse Indicator Type
= None
l
Flammability Rating = UL 94V-1
Contact Related Features:
l
C ontact Type = Steel Strap Screw
l
Pitch (mm [in]) = 16.00 [0.630]
Housing Related Features:
l
Housing Material
= Phenolic
l
Housing C olor = Black
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Temperature, Max. (?C ) = 150
Operation/Application:
l
Application = Heavy Industrial
Other:
l
Brand = Buchanan
Additional Information:
l
Product Line Information
Additional Product Images:
l
Line Drawing
Related Products:
l
Tooling
