TECHNICAL DATA
KK74LS04
Hex Inverters
This device contains six independent inverts. It performs the Boolean
function Y=A.
ORDERING INFORMATION
KK74LS04N Plastic
KK74LS04D SOIC
T
A
= -0° to 70° C for all packages
PIN ASSIGNMENT
LOGIC DIAGRAM
FUNCTION TABLE
Inputs
A
H
L
Output
Y
L
H
PIN 14 =V
CC
PIN 7 = GND
1
KK74LS04
MAXIMUM RATINGS
*
Symbol
V
CC
V
IN
V
OUT
Tstg
*
Parameter
Supply Voltage
Input Voltage
Output Voltage
Storage Temperature Range
Value
7.0
7.0
7.0
-65 to +150
Unit
V
V
V
°C
Maximum Ratings are those values beyond which damage to the device may occur.
Functional operation should be restricted to the Recommended Operating Conditions.
RECOMMENDED OPERATING CONDITIONS
Symbol
V
CC
I
OH
I
OL
T
A
Supply Voltage
High Level Output Current
Low Level Output Current
Ambient Temperature Range
0
Parameter
Min
4.75
Max
5.25
-400
8.0
+70
Unit
V
V
V
°C
DC ELECTRICAL CHARACTERISTICS
over full operating conditions
Guaranteed Limit
Symbol
V
IH
V
IL
V
IK
V
OH
V
OL
I
I
I
IH
I
IL
I
OS
I
CC
Parameter
High Level Input Voltage
Low Level Input Voltage
Input Clamp Voltage
High Level Output Current
Low Level Output Voltage
Input Current at maximum input
voltage
High Level Input Current
Low Level Input Current
Short-circuit output current
Supply Current
V
CC
= min, I
I
= -18 mA
V
CC
= min, V
IL
=max
I
OH
= max
V
CC
= min, V
IH
=min,
I
OL
= 8 mA
V
CC
= max, V
I
= -7V
V
CC
= max, V
IN
= 2.7 V
V
CC
= max, V
IN
= 0.4 V
V
CC
= max (Note)
V
CC
= max
Total with
outputs high
Total with
outputs low
-20
0.1
20
-0.4
-100
2.4
6.6
mA
µA
mA
mA
mA
0.5
V
2.7
Test Conditions
Min
2
0.8
-1.5
Max
Unit
V
V
V
V
Note: Not more than one output should be shorted at a time, and duration should not exceed one second.
2
KK74LS04
AC ELECTRICAL CHARACTERISTICS
(V
CC
= 5.0 V, C
L
= 15 pF, T
A
=25
°C,
R
L
= 2 kΩ,
t
r
=15 ns, t
f
= 6.0 ns)
Symbol
t
PLH
t
PHL
Parameter
Propagation Delay Time
Propagation Delay Time
Min
Max
15
15
Unit
ns
ns
Figure 1. Switching Waveforms
NOTE A. C
L
includes probe and jig capacitance.
Figure 2. Test Circuit
3
KK74LS04
N SUFFIX PLASTIC DIP
(MS - 001AA)
A
14
8
B
1
7
Dimension, mm
Symbol
A
B
C
MIN
18.67
6.1
MAX
19.69
7.11
5.33
0.36
1.14
2.54
7.62
0°
2.92
7.62
0.2
0.38
10°
3.81
8.26
0.36
0.56
1.78
F
L
D
F
C
-T-
SEATING
N
G
D
0.25 (0.010) M T
K
PLANE
G
H
H
J
M
J
K
L
M
N
NOTES:
1. Dimensions “A”, “B” do not include mold flash or protrusions.
Maximum mold flash or protrusions 0.25 mm (0.010) per side.
D SUFFIX SOIC
(MS - 012AB)
Dimension, mm
8
A
14
Symbol
A
MIN
8.55
3.8
1.35
0.33
0.4
1.27
5.27
0°
0.1
0.19
5.8
0.25
MAX
8.75
4
1.75
0.51
1.27
H
B
P
B
C
1
G
7
C
R x 45
D
F
G
-T-
D
0.25 (0.010) M T C M
K
SEATING
PLANE
H
J
F
M
J
K
M
P
R
8°
0.25
0.25
6.2
0.5
NOTES:
1. Dimensions A and B do not include mold flash or protrusion.
2. Maximum mold flash or protrusion 0.15 mm (0.006) per side
for A; for B
‑
0.25 mm (0.010) per side.
4
