30EPH03PBF

Description
30 A, 300 V, SILICON, RECTIFIER DIODE, TO-247AC
CategoryDiscrete semiconductor    diode
File Size114KB,7 Pages
ManufacturerInternational Rectifier ( Infineon )
Websitehttp://www.irf.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

30EPH03PBF Overview

30 A, 300 V, SILICON, RECTIFIER DIODE, TO-247AC

30EPH03PBF Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerInternational Rectifier ( Infineon )
Parts packaging codeTO-247AC
package instructionR-PSFM-T3
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresFREE WHEELING DIODE
applicationULTRA FAST RECOVERY
Shell connectionCATHODE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1 V
JEDEC-95 codeTO-247AC
JESD-30 codeR-PSFM-T3
JESD-609 codee3
Maximum non-repetitive peak forward current300 A
Number of components1
Phase1
Number of terminals3
Maximum operating temperature175 °C
Maximum output current30 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)250
Certification statusNot Qualified
Maximum repetitive peak reverse voltage300 V
Maximum reverse recovery time0.055 µs
surface mountNO
Terminal surfaceMATTE TIN OVER NICKEL
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperature30
Base Number Matches1
Bulletin PD-20882 11/04
30EPH03PbF
Ultrafast Rectifier
Features
Ultrafast Recovery Time
Low Forward Voltage Drop
Low Leakage Current
175°C Operating Junction Temperature
Lead-Free ("PbF" suffix)
t
rr
= 55ns
I
F(AV)
= 30Amp
V
R
= 300V
Description/ Applications
International Rectifier's 300V series are the state of the art Ultrafast recovery rectifiers designed with optimized
performance of forward voltage drop and Ultrafast recovery time.
The planar structure and the platinum doped life time control guarantee the best overall performance, ruggedness
and reliability characteristics.
These devices are intended for use in the output rectification stage of SMPS, UPS, DC-DC converters as well as
freewheeling diodes in low voltage inverters and chopper motor drives.
Their extremely optimized stored charge and low recovery current minimize the switching losses and reduce over
dissipation in the switching element and snubbers.
Absolute Maximum Ratings
Parameters
V
RRM
I
F(AV)
I
FSM
T
J
, T
STG
Repetitive Peak Reverse Voltage
Average Rectified Forward Current
Non Repetitive Peak Surge Current
@ T
C
= 143°C
@ T
J
= 25°C
Max
300
30
300
- 65 to 175
Units
V
A
Operating Junction and Storage Temperatures
°C
Case Styles
30EPH03PbF
BASE
COMMON
CATHODE
2
1
CATHODE
3
ANODE
TO247
www.irf.com
1
