WSL3637
Vishay Dale
Power Metal Strip
®
Resistors, Low Value (down to 0.001
Ω),
Surface Mount, 4-Terminal
FEATURES
•
4-Terminal design allows for 0.5 % resistance
tolerance down to 0.003
Ω
Pb-free
Available
•
Ideal for all types of current sensing, voltage
division and pulse applications including
e3
switching and linear power supplies,
instruments and power amplifiers
•
Proprietary processing technique produces
RoHS*
extremely low resistance values (down to
COMPLIANT
0.001
Ω)
•
All welded construction
•
Solid metal Nickel-Chrome alloy resistive element with low
TCR ( < 20 ppm/°C)
•
Solderable terminations
•
Low thermal EMF (< 3 µV/°C)
•
Very low inductance, 0.5 nH to 5 nH
•
Excellent frequency response to 50 MHz
•
Lead (Pb)-free version is RoHS compliant
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
WSL3637
POWER RATING
P
70 °C
W
3.0
TOLERANCE
%
0.5 and 1.0
RESISTANCE RANGE
Ω
0.001 - 0.01
TECHNICAL SPECIFICATIONS
PARAMETER
Temperature Coefficient
Operating Temperature Range
Maximum Working Voltage
Weight/1000 pieces
UNIT
ppm/°C
°C
V
g
WSL3637
0.001
Ω
- 0.0029
Ω
= ± 75
0.003
Ω
- 0.010
Ω
= ± 50
- 65 to + 170
(P x
R)
1/2
274.3
GLOBAL PART NUMBER INFORMATION
NEW GLOBAL PART NUMBERING: WSL36375L000FTA (PREFERRED PART NUMBERING FORMAT)
W
GLOBAL MODEL
WSL3637
S
L
3
6
3
7
5
L
0
0
0
F
T
A
SPECIAL
(Dash
Number)
(up to 2 digits)
From
1 - 99
as
applicable
VALUE
L
= mΩ*
R
= Decimal
5L000
= 0.005
Ω
R0100
= 0.01
Ω
*
use
”L” for
resistance
values
< 0.01
Ω
TOLERANCE
D
= ± 0.5
%
F
= ± 1.0
%
PACKAGING
EA
= Lead (Pb)-free, tape/reel
EK
= Lead (Pb)-free,
bulk
TA
= Tin/lead, tape/reel (R86)
BA
= Ti n/lead,
bulk
(B43)
HISTORICAL PART NUMBER EXAMPLE: WSL3637 0.005
Ω
1
%
R86 (WILL CONTINUE TO BE ACCEPTED)
WSL3637
HISTORICAL MODEL
0.005
Ω
RESISTANCE
VALUE
1
%
TOLERANCE CODE
R86
PACKAGING
* Pb containing terminations are not RoHS compliant, exemptions may apply
www.vishay.com
22
For technical questions, contact: ww2bresistors@vishay.com
Document Number: 30099
Revision: 26-Mar-07
WSL3637
Power Metal Strip
®
Resistors, Low Value (down to 0.001
Ω),
Surface Mount, 4-Terminal
DIMENSIONS
H
A
L
B
T
W
Vishay Dale
I
d
a
b
c
DIMENSIONS
in inches [millimeters]
MODEL
RESISTANCE RANGE
Ω
W
0.370 ± 0.010
[9.40 ± 0.254]
0.370 ± 0.010
[9.40 ± 0.254]
L
0.360 ± 0.010
[9.14 ± 0.254]
0.360 ± 0.010
[9.14 ± 0.254]
H
0.025 ± 0.010
[0.635 ± 0.254]
0.025 ± 0.010
[0.635 ± 0.254]
T
0.086 ± 0.010
[2.18 ± 0.254]
0.138 ± 0.010
[3.51 ± 0.254]
A
0.061 ± 0.010
[1.55 ± 0.254]
0.061 ± 0.010
[1.55 ± 0.254]
B
0.032 ± 0.010
[0.813 ± 0.254]
0.032 ± 0.010
[0.813 ± 0.254]
0.002 - 0.01
WSL3637
0.001 - 0.0019
SOLDER PAD DIMENSIONS
in inches [millimeters]
MODEL
RESISTANCE RANGE
Ω
a
0.116 [2.95]
0.168 [4.27]
b
0.390 [9.91]
0.390 [9.91]
c
0.066 [1.68]
0.066 [1.66]
d
0.024 [0.610]
0.024 [0.610]
l
0.178 [4.52]
0.074 [1.88]
WSL3637
0.002 - 0.01
0.001 - 0.0019
Rated Power in
%
120
100
80
60
40
20
0
- 65 - 55
- 25
0
25
50
Derating
75 100 125 150 170
70
Ambient Temperature in °C
PERFORMANCE
TEST
Thermal Shock
Short Time Overload
Low Temperature Storage
High Temperature Exposure
Bias Humidity
Mechanical Shock
Vibration
Load Life
Solder Heat
Moisture Resistance
CONDITIONS OF TEST
- 55 °C to + 150 °C, 1000 cycles, 15 min at each extreme
5 x Rated Power for 5 s
- 65 °C for 24 h
1000 h at + 170 °C
+
85
°C,
85
% RH, 10 % Bias, 1000 h
100 g’s for 6 ms, 5 pulses
Frequency varied 10 to 2000 Hz in 1 min, 3 directions, 12 h
1000 h at rated power, + 70 °C, 1.5 h “ON”, 0.5 h “OFF”
+ 260 °C Solder, 10 - 12 s dwell, 25 mm/s emergence
MIL-STD-202, Method 106, 0 % power, 7a and 7b not required
TEST LIMITS
± (0.5 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
± (1.0 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
± (1.0 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
± (0.5 % + 0.0005
Ω) ΔR
PACKAGING
MODEL
WSL3637
REEL
TAPE WIDTH
16 mm/Embossed Plastic
DIAMETER
330 mm/13"
PIECES/REEL
4000
CODE
EA
Note
• Embossed carrier tape per EIA-481-2
Document Number: 30099
Revision: 26-Mar-07
For technical questions, contact: ww2bresistors@vishay.com
www.vishay.com
23
