HEF4751VP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> HEF4751VP

HEF4751VP: DescriptionIC SPECIALTY LOGIC CIRCUIT, PDIP28, PLASTIC, SOT-117, DIP-28, Logic IC:Other; Categorylogic; File Size148KB，10 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

HEF4751VP Overview

IC SPECIALTY LOGIC CIRCUIT, PDIP28, PLASTIC, SOT-117, DIP-28, Logic IC:Other

HEF4751VP Parametric

Parameter Name	Attribute value
Maker	NXP
Parts packaging code	DIP
package instruction	PLASTIC, SOT-117, DIP-28
Contacts	28
Reach Compliance Code	compliant
series	4751
JESD-30 code	R-PDIP-T28
length	35.5 mm
Logic integrated circuit type	LOGIC CIRCUIT
Number of functions	1
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP28,.6
Package shape	RECTANGULAR
Package form	IN-LINE
power supply	5/10 V
Certification status	Not Qualified
Maximum seat height	5.1 mm
Maximum supply voltage (Vsup)	12.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	15.24 mm
Base Number Matches	1

Preview

Download Datasheet

View All

INTEGRATED CIRCUITS

DATA SHEET

For a complete data sheet, please also download:

•

The IC04 LOCMOS HE4000B Logic

Family Specifications HEF, HEC

•

The IC04 LOCMOS HE4000B Logic

Package Outlines/Information HEF, HEC

HEF4751V

LSI

Universal divider

Product speciﬁcation

File under Integrated Circuits, IC04

January 1995

HEF4751VP Related Products

	HEF4751VP	933520200112	HEF4751VT	HEF4751VT-T	HEF4751VTD-T	HEF4751VTD	HEF4751VPN	HEF4751VD	HEF4751VDF
Description	IC SPECIALTY LOGIC CIRCUIT, PDIP28, PLASTIC, SOT-117, DIP-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, CDIP28, CERAMIC, SOT-135V, DIP-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, PDSO28, PLASTIC, SOT-136A, SO-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, PDSO28, PLASTIC, SOT-136A, SO-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, PDSO28, PLASTIC, SOT-136A, SO-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, PDSO28, PLASTIC, SOT-136A, SO-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, PDIP28, PLASTIC, SOT-117, DIP-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, CDIP28, SOT-135V, CERDIP-28, Logic IC:Other	IC SPECIALTY LOGIC CIRCUIT, CDIP28, SOT-135V, CERDIP-28, Logic IC:Other
Maker	NXP	NXP	NXP	NXP	NXP	NXP	NXP	NXP	NXP
Parts packaging code	DIP	DIP	SOIC	SOIC	SOIC	SOIC	DIP	DIP	DIP
package instruction	PLASTIC, SOT-117, DIP-28	DIP,	SOP, SOP28,.4	SOP,	SOP,	SOP,	DIP,	DIP, DIP28,.6	DIP,
Contacts	28	28	28	28	28	28	28	28	28
Reach Compliance Code	compliant	compliant	compliant	unknown	unknown	unknown	unknown	unknown	unknown
series	4751	4751	4751	4751	4751	4751	4751	4751	4751
JESD-30 code	R-PDIP-T28	R-GDIP-T28	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28	R-PDSO-G28	R-PDIP-T28	R-GDIP-T28	R-GDIP-T28
Logic integrated circuit type	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT	LOGIC CIRCUIT
Number of functions	1	1	1	1	1	1	1	1	1
Number of terminals	28	28	28	28	28	28	28	28	28
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	CERAMIC, GLASS-SEALED	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED
encapsulated code	DIP	DIP	SOP	SOP	SOP	SOP	DIP	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	5.1 mm	5.84 mm	2.65 mm	2.65 mm	2.65 mm	2.65 mm	5.1 mm	5.84 mm	5.84 mm
Maximum supply voltage (Vsup)	12.5 V	12.5 V	12.5 V	12.5 V	12.5 V	12.5 V	12.5 V	12.5 V	12.5 V
Minimum supply voltage (Vsup)	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	NO	YES	YES	YES	YES	NO	NO	NO
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING	GULL WING	GULL WING	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
width	15.24 mm	15.24 mm	7.5 mm	7.5 mm	7.5 mm	7.5 mm	15.24 mm	15.24 mm	15.24 mm
Base Number Matches	1	1	1	1	1	1	1	1	1
length	35.5 mm	-	17.9 mm	17.9 mm	17.9 mm	17.9 mm	35.5 mm	-	-
technology	CMOS	-	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
