PS9552L1: Description1 CHANNEL TRANSISTOR OUTPUT OPTOCOUPLER; CategoryLED optoelectronic/LED; File Size295KB，23 Pages; ManufacturerCEL; Websitehttp://www.cel.com/

Download Datasheet Parametric View All

PS9552L1 Overview

1 CHANNEL TRANSISTOR OUTPUT OPTOCOUPLER

PS9552L1 Parametric

Parameter Name	Attribute value
Maximum operating temperature	100 Cel
Minimum operating temperature	-40 Cel
Number of functions	1
Processing package description	Lead FREE, surface mount PACKAGE-8
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	CONSULT MFR
terminal coating	Nickel Palladium
structure	single
Optoelectronic device type	transistor output
Maximum input control current	16 mA
Maximum insulation voltage	5000 V

Preview

Download Datasheet

View All

DATA SHEET

PHOTOCOUPLER

PS9552,PS9552L1,PS9552L2,PS9552L3

2.5 A OUTPUT CURRENT, HIGH CMR

IGBT GATE DRIVE PHOTOCOUPLER

8-PIN DIP PHOTOCOUPLER

DESCRIPTION

The PS9552, PS9552L1, PS9552L2 and PS9552L3 are optically coupled isolators containing a GaAlAs LED on the

input side and a photo diode, a signal processing circuit and a power output transistor on the output side on one chip.

The PS9552 Series is designed specifically for high common mode transient immunity (CMR), high output current

and high switching speed.

The PS9552 Series is suitable for driving IGBTs and MOS FETs.

The PS9552 Series is in a plastic DIP (Dual In-line Package).

The PS9552L1 is lead bending type for long creepage distance.

The PS9552L2 is lead bending type for long creepage distance (Gull-wing) for surface mount.

The PS9552L3 is lead bending type (Gull-wing) for surface mounting.

−NEPOC

Series−

FEATURES

<R>

• Long creepage distance (8 mm MIN.: PS9552L1, PS9552L2)

• Large peak output current (2.5 A MAX., 2.0 A MIN.)

• High speed switching (t

PLH

PHL

= 0.5

s MAX.)

• UVLO (Under Voltage Lock Out) protection with hysteresis

• High common mode transient immunity (CM

, CM

±15

kV/

s MIN.)

• Ordering number of tape product: PS9552L2-E3: 1 000 pcs/reel

: PS9552L3-E3: 1 000 pcs/reel

• Safety standards

• UL approved: File No. E72422

• CSA approved: No. CA 101391

• BSI approved: No. 8937, 8938

• SEMKO approved: No. 615433

• NEMKO approved: No. P06207243

• DEMKO approved: No. 314091

• FIMKO approved: No. FI 22827

• DIN EN60747-5-2 (VDE0884 Part2) approved (Option)

SHIELD

PIN CONNECTION

(Top View)

1. NC

2. Anode

3. Cathode

4. NC

5. V

6. V

7. V

8. V

APPLICATIONS

• IGBT, Power MOS FET Gate Driver

• Industrial inverter

• IH (Induction Heating)

The information in this document is subject to change without notice. Before using this document, please

confirm that this is the latest version.

Document No. PN10589EJ03V0DS (3rd edition)

Date Published October 2007 NS

The mark <R> shows major revised points.

The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.

2006, 2007
