Data Sheet
40W 806nm 30% Fill Factor High Power Laser Diode
Bar on Microchannel Cooler
BAC40C-806-01/02
The Bookham BAC40C-806-01/02 30% fill factor laser diode
bar on microchannel cooler series has been designed to
provide the high output power and high reliability required for
both solid-state laser pumping and direct applications.
The proprietary E2 front mirror passivation process, developed
at our Zurich site, prevents Catastrophic Optical Damage (COD)
to the laser diode facet even at extremely high output powers.
The laser diode bars are mounted on an expansion matched
CuW submount onto a water-cooled microchannel package
providing very high reliability in CW and pulsed (1-Hz type)
applications.
Features:
• Mounted 10mm x 1.2mm laser diode bar
• Active microchannel cooler (water cooled)
• 30% fill factor (150µm emitter / 500µm pitch)
• 40W operating power
• Highly reliable single quantum well MBE structure
• Telecom grade AuSn mounting technology
• Packaging option with Cu base and cover
• RoHS compliant
Applications:
• Collimated solid state laser pumping
• Direct applications such as material processing
• Printing
• Medical
1
Data Sheet
Characteristics
Parameter
CW Output Power
Center Wavelength
[1]
Spectral Width (FWHM)
Wavelength shift with temperature
Beam Divergence (1/e
2
)
Parallel to Junction
Perpendicular to Junction
Polarization
Threshold Current
Slope Efficiency
Conversion Efficiency
Series Resistance
Operating Current
Operating Voltage
Operating Temperature
Microcooler Flow
Microcooler Differential Pressure
[1] Wavelength selectable, extended range on request (780-1060nm).
Symbol
P
op
λ
c
∆λ
dλ
c
/dT
op
θ
//
θ
⊥
-
I
th
η
D
=P
op
/(I
op
-I
th
)
H=P
op
/(V
op
xI
op
)
R
s
I
op
V
op
T
op
Q
w
P
w
Typical
40
806 ± 3
3
0.26
Unit
W
nm
nm
nm/°C
10
34
TE
8
1.1
45
5
50
2
25 ± 5
22 ± 4
0.7
deg
A
W/A
%
mΩ
A
V
°C
l/hrs
bar
Bar Dimensions
Parameter
Bar Width
Resonator Length
Number of Emitters
Emitter Spacing
Emitter Width
Fill Factor
Symbol
b
l
n
p
w
f
Typical
10
1.2
19
500
150
30
Unit
mm
mm
-
µm
µm
%
2
Data Sheet
RoHS Compliance
Bookham is fully committed to environment
protection and sustainable development and has
set in place a comprehensive program for
removing polluting and hazardous substances from
all of its products. The relevant evidence of RoHS
compliance is held as part of our controlled
documentation for each of our compliant products.
RoHS compliance parts are available to order,
please refer to the ordering information section for
further details.
Ordering Information:
BAC40C-806-01
BAC40C-806-02
40W 806nm 30% Fill Factor Laser Diode Bar on Microchannel Cooler
40W 806nm 30% Fill Factor Laser Diode Bar on Microchannel Cooler with Base and Cover
Contact Information
Bookham
(Switzerland) AG
Binzstrasse 17
8045 Zurich
Switzerland
• Tel: +41 44 455 8787
• Fax:+41 44 455 8586
EMEA Sales Contact
Gunnar Stolze
• Tel: +41 79 635 3777
ASIA Sales Contact
Patrick Lee
• Tel: +852 9197 7014
North America
Sales Contact
Michael Cutler
• Tel: +1 678 763 0777
Japan Sales Contact
Japan Laser Corporation
• Tel: +813 5285 0861
www.bookham.com
highpower@bookham.com
Important Notice
Performance figures, data and any illustrative material
provided in this data sheet are typical and must be
specifically confirmed in writing by Bookham before
they become applicable to any particular order or
contract. In accordance with the Bookham policy of
continuous improvement specifications may change
without notice. The publication of information in this
data sheet does not imply freedom from patent or other
protective rights of Bookham or others. Further details
are available from any Bookham sales representative.
DANGER
INVISIBLE LASER RADIATION
AVOID EYE OR SKIN
EXPOSURE TO DIRECT OR
SCATTERED RADIATION
CLASS 4 LASER PRODUCT
INVISIBLE LASER RADIATION -
AVOID EYE OR SKIN EXPOSURE TO
DIRECT OR SCATTERED RADIATION
MAX POWER 40W
WAVELENGTH 806nm
CLASS IV LASER PRODUCT
ISO 9001:2000
Certified
FM 68159
4
REFERENCE IEC 60825-
Edition 1.2
This product complies with
21CFR 1040.10
BH12904 Rev 1.1 June 2007
