40HF(R) Series
STANDARD RECOVERY DIODE
V
RRM
= 100-1600V, I
F(AV)
= 40Amp.
Symbol
A
K
Cathode to Stud Shown
(Anode to Stud add Suffix R)
MAXIMUM RATINGS
Parameter
(Tj = 25 C unless stated otherwise)
40HF(R) 40HF(R)
-10
-20
40HF(R)
-40
40HF(R)
-60
40HF(R)
-80
40HF(R)
-100
40HF(R)
-120
40HF(R) 40HF(R)
-140
-160
Symbol
V
RRM
I
F
(AV)
I
FSM
I
2
T
T
(STG)
Tj
Unit
Volt
Amp
Amp
Repetitive Peak Reverse Voltage
Maximum Average On-State Current
Peak Forward Surge Current 8.3mS
Maximum I
2
T for Fusing 8.3ms
Maximum Storage Temperature Range
Maximum Junction Temperature Range
100
1600
200
400
600
40 at tj = 140
O
C
595
1450
-40 to +190
-40 to +190
800
1000
1200
1400
40 at tj = 110
O
C
500
1050
-65 to +160
-65 to +160
A
2
/S
O
C
C
O
ELECTRICAL CHARACTERISICS at
Parameter
Tj = 25 C Maximum. Unless stated Otherwise
Condition
Symbol
Min
I
FM
=125 Amps (100 -1200V )
I
FM
=125 Amps (1400 -1600V )
V
R
= V
RRM,
tj= tj Max(100 -1200V )
V
R
= V
RRM,
tj= tj Max(1400 -1600V )
V
FM
V
FM
I
RRM
I
RRM
R
TH (J-c)
M
T
Wt
Value
Typ
Max
1.30
1.50
9.0
4.5
0.95
2.5
17
Unit
Volt
Volt
mA
mA
O
Maximum Forward Voltage
Maximum Forward Voltage
Repetitive Peak Reverse Current
Repetitive Peak Reverse Current
Thermal Resistance (Junction to Case)
Mounting Torque
Weight
C/W
NM
grms
Mechanical Outline
0.90
(0.03)
17.25
(0.68)
0 4.0 (0.16) Min
7.0 (0.27) max
6.1 (0.84) min
10.20 (0.401) min
11.4 (0.45) max
14.86 (0.585) Max
12.80 (0.0.503) Min
C
L
4.0 (0.16) min
25.4 (1.00) max
10.6 (0.42) min
11.4 (0.46) max
1/4" 28 UNF - 2A
Metric M6 x 1
Case: DO-203AB (DO-5)
Case: Metal/ Glass to Metal Seal
All Dimensions in Millimeters (Inches)
