RED LASER DIODE
DL-LS1030
Tentative
Features
• Short wavelength : 635 nm (Typ.)
• High output power :5 mW at 60°C
• Low threshold cuttent : lth = 25 mA (Typ.)
Package
Ver.1 Apr. 2002
Tolerance : ± 0.2
(Unit : mm)
0
ø9.0- 0.03
ø5.35
ø4.75± 0.15
ø2.1
Effective window diameter 1.0min.
1
3
2
Top view
Applications
• Bar-code scanner
• Industrial equipment
1.0± 0.1
LD facet
Absolute Maximum Ratings
(Tc=25°C)
Parameter
Light Output
Reverse
Voltage
CW
Laser
PD
V
R
Topr
Tstg
Symbol
Po
Ratings
7
2
30
-10 to +60
-40 to +85
V
°C
°C
2
ø1.4max.
3-
ø0.45± 0.1
Pin No.
1 2 3
ø2.54
Unit
mW
Pin Connection
1
3
Operating Temperature
Storage Temperature
LD
PD
Electrical and Optical Characteristics
Parameter
Threshold Current
Operating Current
Operating Voltage
Lasing Wavelength
Perpendicular
Beam
3)
Divergence
Parallel
Off Axis
Angle
Perpendicular
Parallel
Symbol
Ith
Iop
Vop
Lp
Qv
Qh
dQv
dQh
dPo/dIop
Im
As
1) 2)
(Tc=25°C)
Condition
CW
Po=5mW
Po=5mW
Po=5mW
Po=5mW
Po=5mW
-
-
-
Po=5mW
Po=5mW
Min.
-
-
-
-
25
7
-
-
-
0.08
-
Typ.
25
30
2.2
635
30
9
-
-
0.6
0.12
8
Max.
40
50
2.6
640
35
11
±3
±3
-
0.4
-
Unit
mA
mA
V
nm
°
°
°
°
mW/mA
mA
µm
Differential Efficiency
Monitoring Output Current
Astigmatism
1) Initial values 2) All the above values are evaluated with Tottori Sanyo's measuring apparatus
3) Full angle at half maximum
Note : The above product specification are subject to change without notice.
Tottori SANYO Electric Co., Ltd.
5-318, Tachikawa, Tottori 680-8634 Japan
LED Division
TEL : +81-857-21-2137 FAX : +81-857-21-2161
