NPN PLASTIC POWER TRANSISTOR
SJE1349
TO-220
Plastic Package
Power Linear and Switching Applications
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
Collector Base Voltage
Collector Emitter Voltage
Emitter Base Voltage
Collector Current
Collector Current Peak
Base Current Continuous
Power Dissipation upto T
c
=25ºC
Operating And Storage Junction
Temperature Range
THERMAL RESISTANCE
Junction to Ambient in free air
Junction to Case
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
D
T
j,
T
stg
VALUE
73
63
7
6
10
2
65
- 65 to +150
UNIT
V
V
V
A
A
A
W
ºC
R
th (j-a)
R
th (j-c)
62.5
1.92
ºC/W
ºC/W
ELECTRICAL CHARACTERISTICS (T
c
=25ºC Unless Specified Otherwise)
DESCRIPTION
SYMBOL
TEST CONDITION
*V
CEO (sus)
I
C
=30mA, I
B
=0
Collector Emitter (sus) Voltage
I
CBO
V
CB
=63V, I
E
=0
Collector Cut Off Current
I
CES
V
CE
=73V, V
BE
=0
Collector Cut Off Current
V
EB
=5.2V, I
C
=0
I
EBO
Emitter Cut Off Current
DC Current Gain
Collector Emitter Saturation Voltage
*h
FE
*V
CE (sat)
I
C
=4A, V
CE
=4V
I
C
=4A, I
B
=480mA
I
C
=10A, I
B
=1A
Switching Time
DESCRIPTION
Small Signal Current
Transition Frequency
*Pulse test t
p
<300
µ
s, Duty cycle < 2%
SYMBOL
h
fe
f
T
TEST CONDITION
I
C
=0.5A, V
CE
=10V, f=1KHz
I
C
=0.5A, V
CE
=10V, f=1MHz
MIN
63
TYP
MAX
0.3
0.3
0.9
UNIT
V
mA
mA
mA
V
V
43
100
1.07
3.0
MIN
20
3
TYP
MAX
UNIT
MHz
