8058-1G50 Product Details
Live Product Chat
Transistor Sockets and Adapters
Not re vie we d for R oHS C om pliance
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
8058-1G50
(1447268-1)
T E I nternal N umber: 1 4 4 7 2 6 8 - 1
Product Highlights:
l
Socket
l
Terminal Style = Printed C ircuit
l
Terminal C onfiguration = C ontact
l
Lead Size Accepted = .41 mm
l
8 Terminals
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Socket
l
Terminal C onfiguration = C ontact
l
Product Series = 8058 Series
l
Package = TO-5
l
Sleeve Material = Brass
l
Profile = Low
Electrical Characteristics:
l
Lead Length Accepted (mm [in]) = 3.18 – 3.94 [0.125 – 0.155]
l
Pin C ircle Diameter (mm [in]) = 5.84 [0.230]
Termination Related Features:
l
Terminal Plating = Gold
Body Related Features:
l
Terminal Style = Printed C ircuit
l
Number of Terminals = 8
l
Post Diameter (mm [in]) = 0.51 [0.020]
l
Socket Type = Transistor
l
Terminal Material = Beryllium C opper
l
Insulator Material = Teflon
Contact Related Features:
l
Sleeve Plating = Gold
Configuration Related Features:
l
Lead Size Accepted (mm [in]) = 0.41 [0.016]
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
Operating Temperature (?C ) = -55 – +125
Other:
l
Brand = AMP
