*Notice: The information in this document is subject to change without notice
December 1, 2006
DSC 6923
IDT 89HPES16T4 Data Sheet
Power Management
– Utilizes advanced low-power design techniques to achieve low
typical power consumption
– Supports PCI Power Management Interface specification
(PCI-PM 1.1)
– Unused SerDes are disabled
– Supports Advanced Configuration and Power Interface Spec-
ification, Revision 2.0 (ACPI) supporting active link state
◆
Testability and Debug Features
– Ability to read and write any internal register via the SMBus
◆
Eleven General Purpose Input/Output Pins
– Each pin may be individually configured as an input or output
– Each pin may be individually configured as an interrupt input
– Some pins have selectable alternate functions
◆
Packaged in a 23mm x 23mm 484-ball BCG with 1mm ball
spacing
◆
Bit
1
2
3
4
5
6
7
Slave
SMBus
Address
SSMBADDR[1]
SSMBADDR[2]
SSMBADDR[3]
0
SSMBADDR[5]
1
1
Master
SMBus
Address
MSMBADDR[1]
MSMBADDR[2]
MSMBADDR[3]
MSMBADDR[4]
1
0
1
Table 1 Master and Slave SMBus Address Assignment
Product Description
Utilizing standard PCI Express interconnect, the PES16T4 provides
the most efficient I/O connectivity solution for applications requiring high
throughput, low latency, and simple board layout with a minimum
number of board layers. It provides 8 GBps (64 Gbps) of aggregated,
full-duplex switching capacity through 16 integrated serial lanes, using
proven and robust IDT technology. Each lane provides 2.5 Gbps of
bandwidth in both directions and is fully compliant with PCI Express
Base specification revision 1.1.
SMBus Interface
The PES16T4 contains two SMBus interfaces. The slave interface
provides full access to the configuration registers in the PES16T4,
allowing every configuration register in the device to be read or written
by an external agent. The master interface allows the default configura-
tion register values of the PES16T4 to be overridden following a reset
with values programmed in an external serial EEPROM. The master
interface is also used by an external Hot-Plug I/O expander.
Six pins make up each of the two SMBus interfaces. These pins
consist of an SMBus clock pin, an SMBus data pin, and 4 SMBus
address pins. In the slave interface, these address pins allow the
SMBus address to which the device responds to be configured. In the
master interface, these address pins allow the SMBus address of the
serial configuration EEPROM from which data is loaded to be config-
ured. The SMBus address is set up on negation of PERSTN by
sampling the corresponding address pins. When the pins are sampled,
the resulting address is assigned as shown in Table 1.
As shown in Figure 2, the master and slave SMBuses may be used
in a unified or split configuration. In the unified configuration, shown in
Figure 2(a), the master and slave SMBuses are tied together and the
PES16T4 acts both as a SMBus master as well as a SMBus slave on
this bus. This requires that the SMBus master or processor that has
access to PES16T4 registers supports SMBus arbitration. In some
systems, this SMBus master interface may be implemented using
general purpose I/O pins on a processor or micro controller, and may
not support SMBus arbitration. To support these systems, the PES16T4
may be configured to operate in a split configuration as shown in Figure
2(b).
In the split configuration, the master and slave SMBuses operate as
two independent buses and thus multi-master arbitration is never
required. The PES16T4 supports reading and writing of the serial
EEPROM on the master SMBus via the slave SMBus, allowing in
system programming of the serial EEPROM.
2 of 30
*Notice: The information in this document is subject to change without notice
December 1, 2006
IDT 89HPES16T4 Data Sheet
PES16T4
Processor
SMBus
Master
Serial
EEPROM
...
Other
SMBus
Devices
PES16T4
Processor
SMBus
Master
...
Other
SMBus
Devices
SSMBCLK
SSMBDAT
MSMBCLK
MSMBDAT
SSMBCLK
SSMBDAT
MSMBCLK
MSMBDAT
Serial
EEPROM
(a) Unified Configuration and Management Bus
(b) Split Configuration and Management Buses
Figure 2 SMBus Interface Configuration Examples
Hot-Plug Interface
The PES16T4 supports PCI Express Hot-Plug on each downstream port. To reduce the number of pins required on the device, the PES16T4
utilizes an external I/O expander, such as that used on PC motherboards, connected to the SMBus master interface. Following reset and configura-
tion, whenever the state of a Hot-Plug output needs to be modified, the PES16T4 generates an SMBus transaction to the I/O expander with the new
value of all of the outputs. Whenever a Hot-Plug input changes, the I/O expander generates an interrupt which is received on the IOEXPINTN input pin
(alternate function of GPIO) of the PES16T4. In response to an I/O expander interrupt, the PES16T4 generates an SMBus transaction to read the
state of all of the Hot-Plug inputs from the I/O expander.
General Purpose Input/Output
The PES16T4 provides 11 General Purpose Input/Output (GPIO) pins that may be used by the system designer as bit I/O ports. Each GPIO pin
may be configured independently as an input or output through software control. Some GPIO pins are shared with other on-chip functions. These
alternate functions may be enabled via software, SMBus slave interface, or serial configuration EEPROM.
The PES16T4 is based on a flexible and efficient layered architecture. The PCI Express layer consists of SerDes, Physical, Data Link and Trans-
action layers in compliance with PCI Express Base specification Revision 1.1. The PES16T4 can operate either as a store and forward or cut-through
switch and is designed to switch memory and I/O transactions. It supports eight Traffic Classes (TCs) and one Virtual Channel (VC) with sophisticated
resource management to enable efficient switching and I/O connectivity for servers, storage, and embedded applications.
Processor
Processor
North
Bridge
Memory
Memory
Memory
Memory
x4
PES16T4
x4
PCI Express
Slot
x4
I/O
10GbE
x4
I/O
10GbE
I/O
SATA
I/O
SATA
Figure 3 I/O Expansion Application
3 of 30
December 1, 2006
IDT 89HPES16T4 Data Sheet
Pin Description
The following tables list the functions of the pins provided on the PES16T4. Some of the functions listed may be multiplexed onto the same pin.
The active polarity of a signal is defined using a suffix. Signals ending with an “N” are defined as being active, or asserted, when at a logic zero (low)
level. All other signals (including clocks, buses, and select lines) will be interpreted as being active, or asserted, when at a logic one (high) level.
Note:
In the PES16T4, the three downstream ports are labeled port 1, port 6, and port 7.
Signal
PE0RP[3:0]
PE0RN[3:0]
PE0TP[3:0]
PE0TN[3:0]
PE1RP[3:0]
PE1RN[3:0]
PE1TP[3:0]
PE1TN[3:0]
PE6RP[3:0]
PE6RN[3:0]
PE6TP[3:0]
PE6TN[3:0]
PE7RP[3:0]
PE7RN[3:0]
PE7TP[3:0]
PE7TN[3:0]
P01MERGEN
Type
I
O
I
Name/Description
PCI Express Port 0 Serial Data Receive.
Differential PCI Express receive
pairs for port 0. Port 0 is the upstream port.
PCI Express Port 0 Serial Data Transmit.
Differential PCI Express trans-
mit pairs for port 0. Port 0 is the upstream port.
PCI Express Port 1 Serial Data Receive.
Differential PCI Express receive
pairs for port 1. When port 0 is merged with port 1, these signals become
port 0 receive pairs for lanes 4 through 7.
PCI Express Port 1 Serial Data Transmit.
Differential PCI Express trans-
mit pairs for port 1. When port 0 is merged with port 1, these signals
become port 0 transmit pairs for lanes 4 through 7.
PCI Express Port 6 Serial Data Receive.
Differential PCI Express receive
pairs for port 6.
PCI Express Port 6 Serial Data Transmit.
Differential PCI Express trans-
mit pairs for port 6.
PCI Express Port 7 Serial Data Receive.
Differential PCI Express receive
pairs for port 7. When port 6 is merged with port 7, these signals become
port 6 receive pairs for lanes 4 through 7.
PCI Express Port 7 Serial Data Transmit.
Differential PCI Express trans-
mit pairs for port 7. When port 6 is merged with port 7, these signals
become port 6 transmit pairs for lanes 4 through 7.
Port 0 and 1 Merge.
When this pin is asserted, port 1 is merged with port 0
to form a single x8 port. The SerDes lanes associated with port 1 become
lanes 4 through 7 of port 0.
Port 6 and 7 Merge.
When this pin is asserted, port 7 is merged with port 6
to form a single x8 port. The SerDes lanes associated with port 3 become
lanes 4 through 7 of port 6.
PCI Express Reference Clock.
Differential reference clock pair input. This
clock is used as the reference clock by on-chip PLLs to generate the clocks
required for the system logic and on-chip SerDes. The frequency of the dif-
ferential reference clock is determined by the REFCLKM signal.
PCI Express Reference Clock Mode Select.
This signal selects the fre-
quency of the reference clock input.
0x0 - 100 MHz
0x1 - 125 MHz
Table 2 PCI Express Interface Pins
O
I
O
I
O
I
P67MERGEN
I
PEREFCLKP[2:1]
PEREFCLKN[2:1]
I
REFCLKM
I
4 of 30
December 1, 2006
IDT 89HPES16T4 Data Sheet
Signal
MSMBADDR[4:1]
MSMBCLK
MSMBDAT
SSMBADDR[5,3:1]
SSMBCLK
SSMBDAT
Type
I
I/O
I/O
I
I/O
I/O
Name/Description
Master SMBus Address.
These pins determine the SMBus address of the
serial EEPROM from which configuration information is loaded.
Master SMBus Clock.
This bidirectional signal is used to synchronize
transfers on the master SMBus.
Master SMBus Data.
This bidirectional signal is used for data on the mas-
ter SMBus.
Slave SMBus Address.
These pins determine the SMBus address to
which the slave SMBus interface responds.
Slave SMBus Clock.
This bidirectional signal is used to synchronize trans-
fers on the slave SMBus.
Slave SMBus Data.
This bidirectional signal is used for data on the slave
SMBus.
Table 3 SMBus Interface Pins
Signal
GPIO[0]
GPIO[1]
GPIO[2]
GPIO[3]
GPIO[4]
Type
I/O
I/O
I/O
I/O
I/O
Name/Description
General Purpose I/O.
This pin can be configured as a general purpose I/O pin.
General Purpose I/O.
This pin can be configured as a general purpose I/O pin.
General Purpose I/O.
This pin can be configured as a general purpose I/O pin.
General Purpose I/O.
This pin can be configured as a general purpose I/O pin.
General Purpose I/O.
This pin can be configured as a general purpose I/O pin.
