XC6134N28FER-G

Description
Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDSO6, USP-6
CategoryThe power supply circuit
File Size526KB,28 Pages
ManufacturerTOREX
Websitehttp://www.torex.co.jp/chinese/
Environmental Compliance
Download Datasheet Parametric View All

XC6134N28FER-G Overview

Power Supply Support Circuit, Adjustable, 1 Channel, CMOS, PDSO6, USP-6

XC6134N28FER-G Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTOREX
package instructionHVSON,
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Other featuresDETECT VOLTAGE IS 2.8V
Adjustable thresholdYES
Analog Integrated Circuits - Other TypesPOWER SUPPLY SUPPORT CIRCUIT
JESD-30 codeR-PDSO-N6
length2 mm
Humidity sensitivity level1
Number of channels1
Number of functions1
Number of terminals6
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
encapsulated codeHVSON
Package shapeRECTANGULAR
Package formSMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)260
Maximum seat height0.6 mm
Maximum supply voltage (Vsup)6 V
Minimum supply voltage (Vsup)1.6 V
Nominal supply voltage (Vsup)2 V
surface mountYES
technologyCMOS
Temperature levelAUTOMOTIVE
Terminal surfaceNickel/Silver/Gold (Ni/Ag/Au)
Terminal formNO LEAD
Terminal pitch0.5 mm
Terminal locationDUAL
Maximum time at peak reflow temperature10
width1.8 mm
Base Number Matches1
XC6134 Series
ETR02029-001
Delay capacitor adjustable voltage detectors with sense pin isolation and HYS
external adjustment
■GENERAL
DESCRIPTION
The XC6134 series are ultra-small delay capacitor adjustable type voltage detectors that have high accuracy and sense pin
isolation. High accuracy and a low supply current are achieved by means of a CMOS process, a highly accurate reference
power supply, and laser trimming technology.
The sense pin is isolated from the power input pin to enable monitoring of the voltage of another power supply. Output can be
maintained in the detection state even if the voltage of the power supply that is monitored drops to 0V. The sense pin is also
suitable for detecting high voltages, and the detection and release voltage can be set as desired using external resistors. An
internal delay circuit is also provided. By connecting a capacitor to the Cd/MRB pin, any release delay time and detect delay
time can be set, and the pin can also be used as a manual reset pin. The HYS external adjustment pin can be used to
establish a sufficient hysteresis width.
■APPLICATIONS
●Microcontroller
reset and malfunction monitoring
●Battery
voltage monitoring
●System
power-on reset
●Power
failure detection
■FEATURES
: -40℃½+125℃
: 1.6V½6.0V
: 0.8V½5.0V
: ±18mV(V
DF
<1.5V)
: ±1.2%(1.5V≦V
DF
≦3.0V)
: ±1.5%(3.1V≦V
DF
≦5.0V)
: ±36mV(V
DF
<1.5V)
Detect voltage accuracy
: ±2.7%(1.5V≦V
DF
≦3.0V)
(Ta=-40½125℃)
: ±3.0%(3.1V≦V
DF
≦5.0V)
: ±50ppm/℃(TYP.)
Temperature Characteristics
: V
DF
×0.1%(TYP.)
Hysteresis width
Adjustable Pin for Hysteresis Width : Yes
: 1.28μA(TYP.)
Low supply current
V
IN
=1.6V(At detection)
: 1.65μA(TYP.)
V
IN
=6.0V(At release)
: Yes (For details, refer to
Manual reset function
FUNCTION CHART)
: CMOS or Nch open drain
Output type
: H level or L level at detection
Output logic
: Release delay / detection delay
Delay capacitance pin
can be set in 5 time ratio options
(For details, refer to Selection Guide).
: USP-6C,SOT-26
Packages
: EU RoHS compliant, Pb free
Environment friendly
Operating Ambient Temperature
Operating voltage range
Detect voltage range
Detect voltage accuracy
(Ta=25℃)
■TYPICAL
APPLICATION CIRCUIT
■TYPICAL
PERFORMANCE
CHARACTERISTICS
+B
R3
HYS
V
SEN
V
DD
V
IN
=3.3V、V
SEN
=0V→6V→0V
R1=330kΩ
R1
V
IN
Rpull
(*1)
4.0
XC6134C10B
R2
RESET
SW
Cd
Cd/MRB
V
SS
RESET
RESETB
Output Voltage : V
RESET
(V)
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
R3=0Ω
R3=330kΩ
R3=110kΩ
GND
Battery (+B) voltage monitoring: Detects high voltage
by R1/R2 resistance dividing.
A hysteresis width can be added as desired by
connecting R3 between the V
SEN
and HYS pins
(For details, refer to OPERATIONAL DESCRIPTION).
V
SEN
pin Voltage : V
SEN
(V)
1/28
