Home > Products > Relays > Product Feature Selector > Product Details
514150711 Product Details
Industrial Relays (General Purpose)
Converted to EU RoHS but not ELV Compliant
(
Statement of Compliance
)
Product Highlights:
RM 2/3/7 Series
Contact Current Class = 10A to 20A Class, Greater
Than 16A
Contact Rated Current = 16 A
Terminal Type = Plugin, Quick Connect
Contact Arrangement = 3 Form C (CO)
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
514150711
TE Internal Number: 514150711
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
Power Relay RM2/3/7 (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 10A to 20A Class, Greater Than 16A
Contact Rated Current (A) = 16
Contact Limiting Continuous Current (A) = 16
Contact Limiting Making Current (A) = 40
Contact Limiting Breaking Current (A) = 16
Insulation Initial Dielectric Between Coil/Contact Class = 1500V to
2500VA Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 1500
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
2500
Contact Rated Voltage (VAC) = 400
Contact Switching Voltage Max. (VAC) = 440
Contact Limiting ShortTime Current (A) = 16
Contact Switching Recommended Load, Min. = 100mA at 24V
Coil Rated Voltage (VAC) = 400
Coil Resistance (Ω) = 23500
Coil Rated Power, AC (VA) = 3.00
Coil Rated Power Class = 2.0VA to 3.0VA Class
Insulation Initial Dielectric Between Adjacent Contacts (V rms) =
2500
Insulation Creepage Class = >8mm Class
Insulation Clearance Class = 2.5mm to 4mm Class
Insulation Special Features = 4000V Initial Surge Withstand Voltage
between Contacts and Coil
Dimensions:
Mechanical Length Class = 35mm to 40mm Class
Body Features:
Mount Type = Bracket
Weight (g [oz]) = 81.00 [2.859]
Contact Features:
Terminal Type = Plugin, Quick Connect
Contact Material = AgCdO
Contact Number of Poles = 3
Configuration Features:
Contact Arrangement = 3 Form C (CO)
Coil Magnetic System = Monostable, AC
Coil Special Features = UL Coil Insulation Class B
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Converted to comply with RoHS not
ELV directives
Approved/Registered Standards = cULus, VDE
Environmental:
Environmental Category of Protection = RTI
Environmental Ambient Temperature, Max. (°C [°F]) = 50 [122]
Environmental Ambient Temperature Class = 0 to 50°C Class
Packaging Features:
Packaging Method = Tray
Length (mm [in]) = 38.50 [1.515]
Mechanical Width Class = 30mm to 40mm Class
Width (mm [in]) = 35.50 [1.398]
Mechanical Height Class = 40mm to 50mm Class
Height (mm [in]) = 48.50 [1.909]
Insulation Clearance Between Contact and Coil (mm [in]) = 4
[0.157]
Insulation Creepage Between Contact and Coil (mm [in]) = 14.9
[0.587]
Other:
Series = RM 2/3/7
Brand = Schrack
Additional Features = Mechanical Indicator, Manual Operation
