BMIS-205-C datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> BMIS-205-C

BMIS-205-C: DescriptionEMI Gaskets, Sheets & Absorbers BMIS-205 Cover 1.50" x 1.00"; CategoryPassive components; File Size105KB，1 Pages; ManufacturerLaird; Environmental Compliance

Download Datasheet Parametric Compare View All

BMIS-205-C Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BMIS-205-C	-	-	View	Buy Now

BMIS-205-C Overview

EMI Gaskets, Sheets & Absorbers BMIS-205 Cover 1.50" x 1.00"

BMIS-205-C Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Laird
Product Category	EMI Gaskets, Sheets & Absorbers
RoHS	Details
Product	Shields
Type	Open Frame Shields & Enclosures
Mounting Style	SMD/SMT
Length	38.1 mm
Width	25.4 mm
Thickness	6 mm
Packaging	Bulk
Factory Pack Quantity	250
Unit Weight	0.038801 oz

Preview

Download Datasheet

View All

Laird Technologies

Web site: www.LairdTech.com

Standard Surface Mount Shields-Two-Piece

Two-piece board level shields offer users the flexibility to inspect or repair shielded components without having to risk board

damage by removing the entire shield or incur any tooling costs. Covers snap on and off with ease, which makes repair of

the component under the shield quicker and easier and reduces board re-work. Two-piece shields are available

unassembled(Pre-assembly is an option), and are designed to survive drop, shock and no-rattle tests.

Results 1 - 8 of 8

Item #

BMIS-201

BMIS-202

BMIS-203

BMIS-204

BMIS-205

BMIS-206

BMIS-207

BMIS-210

Item Name

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Standard Surface Mount

Shields-Two-Piece

Surface Area

0.253 inches&#178

0.402 inches&#178

1.033 inches&#178

1.548 inches&#178

1.461 inches&#178

1.879 inches&#178

2.997 inches&#178

2.080 inches&#178

Maximum Overall

Dimension

0.476 x 0.538 inches

0.650 x 0.650 inches

1.032 x 1.032 inches

1.260 x 1.260 inches

1.000 x 1.500 inches

1.326 x 1.450 inches

1.747 x 1.747 inches

1.201 x 1.732 inches

Maximum Overall Height

0.1 inches

0.142 inches

0.2 inches

0.236 inches

0.2 inches

0.384 inches

0.118 inches

Material

0.20 mm CRS Tin

Results 1 - 8 of 8

9/16/2011 | Page 1 of 1

BMIS-205-C Related Products

	BMIS-205-C	BMIS-203-C	BMIS-206-F	BMIS-202-C	BMIS-207-C	BMIS-203-F	BMIS-201-C
Description	EMI Gaskets, Sheets & Absorbers BMIS-205 Cover 1.50" x 1.00"	EMI Gaskets, Sheets & Absorbers BMIS-203 Cover 1.032"x1.032"	EMI Gaskets, Sheets & Absorbers BMIS-206 Frame 1.450"x1.326"	EMI Gaskets, Sheets & Absorbers BMIS-202 Cover .650" x .650"	EMI Gaskets, Sheets & Absorbers BMIS-207 Cover 1.747"x1.747"	EMI Gaskets, Sheets & Absorbers BMIS-203 Frame 1.032"x1.032"	EMI Gaskets, Sheets & Absorbers BMIS-201 Cover .538" x .476"
Product Attribute	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value
Manufacturer	Laird	Laird	Laird	Laird	Laird	Laird	Laird
Product Category	EMI Gaskets, Sheets & Absorbers	EMI Gaskets, Sheets & Absorbers	EMI Gaskets, Sheets & Absorbers	EMI Gaskets, Sheets & Absorbers	EMI Gaskets, Sheets & Absorbers	EMI Gaskets, Sheets & Absorbers	EMI Gaskets, Sheets & Absorbers
RoHS	Details	Details	Details	Details	Details	Details	Details
Product	Shields	Shields	Shields	Shields	Shields	Shields	Shields
Type	Open Frame Shields & Enclosures	Open Frame Shields & Enclosures	Open Frame Shields & Enclosures	Open Frame Shields & Enclosures	Open Frame Shields & Enclosures	Open Frame Shields & Enclosures	Open Frame Shields & Enclosures
Mounting Style	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT
Length	38.1 mm	26.21 mm	36.83 mm	16.5 mm	44.37 mm	26.21 mm	13.66 mm
Width	25.4 mm	26.21 mm	33.68 mm	16.5 mm	44.37 mm	26.21 mm	12.1 mm
Thickness	6 mm	5.08 mm	5.08 mm	3.6 mm	9.75 mm	5.08 mm	2.54 mm
Factory Pack Quantity	250	300	300	700	1	300	1
Unit Weight	0.038801 oz	0.028219 oz	0.089490 oz	0.010582 oz	0.599657 oz	0.052911 oz	0.007055 oz
Packaging	Bulk	Bulk	Reel	Bulk	Bulk	Reel	Bulk
