TA2003FG datasheet, PDF - EEWORLD Datasheet

TA2003FG: DescriptionAM / FM Radio IC; CategoryAnalog mixed-signal IC Consumption circuit; File Size365KB，11 Pages; ManufacturerToshiba Semiconductor; Websitehttp://toshiba-semicon-storage.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

TA2003FG Overview

AM / FM Radio IC

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	SSOP,
Contacts	16
Reach Compliance Code	unknow
Commercial integrated circuit types	AUDIO SINGLE CHIP RECEIVER
Demodulation type	AM/FM
harmonic distortion	1%
JESD-30 code	R-PDSO-G16
length	8.2 mm
Number of functions	1
Number of terminals	16
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Output voltage nominal (AM)	60 mV
Nominal output voltage (FM)	70 mV
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	1.9 mm
Signal-to-noise ratio Nom (FM)	62 dB
Maximum supply voltage (Vsup)	7 V
Minimum supply voltage (Vsup)	1.8 V
surface mount	YES
technology	BIPOLAR
Temperature level	COMMERCIAL EXTENDED
Terminal form	GULL WING
Terminal pitch	1 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	4.6 mm
Base Number Matches	1

TA2003PG/FG

TOSHIBA Bipolar Linear Integrated Circuit Silicon Monolithic

TA2003PG,TA2003FG

AM / FM Radio IC

The TA2003PG, TA2003FG are AM / FM radio IC (FM F / E+AM

/ FM IF) which are designed for AM / FM radios.

Combining with the TA7368P (Mono PW IC), a suitable AM / FM

radio system is able to be constituted.

TA2003PG

Features

•

FM IFT, AM IFT and FM detector coil are not needed.

Pin compatible of TA8164P.

Operating supply voltage range

: V

CC (opr)

= 1.8~7V (Ta = 25°C)

TA2003FG

Weight

DIP16−P−300−2.54A: 1.00g (typ.)

SSOP16−P−225−1.00A: 0.14g (typ.)

2006-04-11

	TA2003FG	TA2003PG
Description	AM / FM Radio IC	AM / FM Radio IC
Is it Rohs certified?	conform to	conform to
Parts packaging code	SOIC	DIP
package instruction	SSOP,	DIP,
Contacts	16	16
Reach Compliance Code	unknow	unknow
Commercial integrated circuit types	AUDIO SINGLE CHIP RECEIVER	AUDIO SINGLE CHIP RECEIVER
Demodulation type	AM/FM	AM/FM
harmonic distortion	1%	1%
JESD-30 code	R-PDSO-G16	R-PDIP-T16
length	8.2 mm	19.25 mm
Number of functions	1	1
Number of terminals	16	16
Maximum operating temperature	75 °C	75 °C
Minimum operating temperature	-25 °C	-25 °C
Output voltage nominal (AM)	60 mV	60 mV
Nominal output voltage (FM)	70 mV	70 mV
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SSOP	DIP
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified
Maximum seat height	1.9 mm	4.45 mm
Signal-to-noise ratio Nom (FM)	62 dB	62 dB
Maximum supply voltage (Vsup)	7 V	7 V
Minimum supply voltage (Vsup)	1.8 V	1.8 V
surface mount	YES	NO
technology	BIPOLAR	BIPOLAR
Temperature level	COMMERCIAL EXTENDED	COMMERCIAL EXTENDED
Terminal form	GULL WING	THROUGH-HOLE
Terminal pitch	1 mm	2.54 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
width	4.6 mm	7.62 mm
Base Number Matches	1	1
