IllumInatIon
For nEW designs consider
this replacement product:
•
LUXEON 5050
N
o o
r L
d o
er N
g
a e
b r
Le
luXEon 5258
Multi-die, single LED for effective
single source lamps
LUXEON 5258 is a multi-die package LED that provides high luminance
from a single package to enable cost effective, single optic and directional
lamp designs. LUXEON 5258 uses an industry standard 5258 surface
mount package and is available in 24V and 96V to interface with high
efficiency drivers. LUXEON 5258 comes in 70, 80 and 90CRI in wide range
of CCTs and offers hot-color targeting to ensure that the LEDs are within
color target at application conditions of 85°C.
FEaturEs and BEnEFIts
PrImary aPPlIcatIons
High Bay & Low Bay
Lamps
5mm optical source enables good optic design for great punch
Hot-color targeting ensures color is within ANSI bin at 85°C
Binned within 3-step and 5-step MacAdam ellipse ensuring color uniformity
Compatible with low cost and high efficiency drivers
Available in 24V and 96V options
Outdoor
Spotlights
DS211 LUXEON 5258 Product Datasheet ©2016 Lumileds Holding B.V. All rights reserved.
No. E352519
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical and Thermal Characteristics.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
N
o o
r L
d o
er N
g
a e
b r
Le
DS211 LUXEON 5258 Product Datasheet 20161004 ©2016 Lumileds Holding B.V. All rights reserved.
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Spectral Power Distribution Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Light Output Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Forward Current Characteristics.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
Radiation Pattern Characteristics
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Decoding Product Bin Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Luminous Flux Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Color Bin Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Bin and Labeling Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Reflow Soldering Guidelines
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
JEDEC Moisture Sensitivity
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pocket Tape Dimensions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Reel Dimensions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
i
General Product Information
Product Test Conditions
LUXEON 5258 LEDs are tested and binned at 160mA for 24V products and 40mA for 96V products at a junction temperature,
T
j
, of 25ºC.
N
o o
r L
d o
er N
g
a e
b r
Le
Part Number Nomenclature
Part numbers for LUXEON 5258 follow the convention below:
L 1 5 2 –
A A B B
5 0
D D
0 0 0 0 0
Where:
A A
–
B B
–
D D
–
designates CCT (27=2700K, 30=3000K, 40=4000K, 50=5000K, 57=5700K)
designates minimum CRI (70=70CRI, 80=8-CRI, 90=90CRI)
designates forward voltage (24=24V and 96=96V)
Therefore, the following part number is used for a LUXEON 5258 3000K 80CRI 24V:
L 1 5 2 –
3 0 8 0
5 0
2 4
0 0 0 0 0
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the long-
term performance of this product.
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON 5258
is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely the
materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or polybrominated
diphenyl ethers (PBDE).
RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the following restricted
DS211 LUXEON 5258 Product Datasheet 20161004 ©2016 Lumileds Holding B.V. All rights reserved.
2
Performance Characteristics
Product Selection Guide
Table 1 . Product performance of LUXEON 5258 at test current, T
j
=25ºC .
VoltagE
nomInal
cct
[1]
4000
5000
5700
2700
3000
4000
2700
3000
4000
mInImum
crI
70
70
70
80
80
80
90
90
90
lumInous FluX
[2]
(lm)
mInImum
550
550
530
460
475
520
425
440
470
tyPIcal
590
590
590
485
500
550
450
465
495
tyPIcal
lumInous
EFFIcacy (lm/W)
148
148
148
121
125
138
113
116
124
tEst currEnt
(ma)
160
160
160
160
160
160
160
160
160
40
40
Part numBEr
L152-4070502400000
L152-5070502400000
L152-5770502400000
L152-2780502400000
L152-3080502400000
L152-4080502400000
L152-2790502400000
L152-3090502400000
L152-4090502400000
L152-2780509600000
L152-3080509600000
N
o o
r L
d o
er N
g
a e
b r
Le
24V
96V
2700
3000
80
80
400
410
445
458
115
118
Notes for Table 1:
1.
Correlated color temperature is based upon mounted die on highly reflective surface at T
j
=25°C.
2.
Lumileds maintains a tolerance of ±2 on CRI and ±7% on luminous flux measurements.
Optical Characteristics
Part numBEr
Table 2 . Optical characteristics for LUXEON 5258 at test current, T
j
=25ºC .
tyPIcal total IncludEd anglE
[1]
135°
tyPIcal VIEWIng anglE
[2]
115°
L152-xx8050xx00000
Notes for Table 2:
1.
Total angle at which 90% of total luminous flux is captured.
2.
Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
DS211 LUXEON 5258 Product Datasheet 20161004 ©2016 Lumileds Holding B.V. All rights reserved.
3
Electrical and Thermal Characteristics
Table 3 . Electrical and thermal characteristics for LUXEON 5258 at test current, T
j
=25ºC .
Part numBEr
L152-xx80502400000
L152-xx80509600000
ForWard VoltagE (V
f
)
[1]
mInImum
23.5
92.0
tyPIcal
25.0
97.0
maXImum
26.5
100.0
tyPIcal tEmPEraturE
coEFFIcIEnt oF ForWard
VoltagE (mV/°c)
[2]
-17
-50
tyPIcal thErmal
rEsIstancE — JunctIon
to soldEr Pad (°c/W)
1.5
1.5
N
o o
r L
d o
er N
g
a e
b r
Le
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON 5258 .
ParamEtEr
maXImum PErFormancE
24V=240mA
96V=60mA
24V=300mA
96V=80mA
125°C
Class 3B
DC Forward Current
[1, 2]
Peak Pulsed Forward Current
[1, 3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
Storage Temperature
-40°C to 105°C
-40°C to 105°C
Reverse Voltage (V
reverse
)
LUXEON LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1. Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2.
Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed the maximum peak pulsed forward current
3.
At 10% duty cycle with pulse width of 10ms.
Notes for Table 3:
1.
Lumileds maintains a tolerance of ±6% on forward voltage measurements.
2.
Measured between 25°C and 85°C.
DS211 LUXEON 5258 Product Datasheet 20161004 ©2016 Lumileds Holding B.V. All rights reserved.
4
