REVISIONS
DATAPLATE
REV
1
2
ECO NO.
23573
DESCRIPTION
ORIGINAL RELEASE
UPDATED & REDRAWN
BY
JWS
TonyD
DATE
3/25/1986
3/24/2015
APP'D BY
TS
DATE
3/25/1986
UNCONTROLLED DOCUMENT
WILL NOT BE UPDATED
DIMENSIONS IN INCHES - UNLESS OTHERWISE SPECIFIED
2.00 MAX
1.38
TURRET
LATCH
1.50
INSERT
COLOR
BLUE
RED
GREEN
HOLE
DIMENSIONS
.096
.686
.125
.892
.125
.779
ADDITIONAL
FEATURES
.125
.472
RANDOM ORDER OF
ROTATION IS ACCEPTABLE
FOR POSITIONER INSERTS
MATERIAL
TURRET
ITEM
PART NO.
DATE
QTY.
DESCRIPTION / REMARKS
DANIELS MANUFACTURING CORP.
ORLANDO, FLORIDA
CAGE 11851
N/A
RESTRICTED & CONFIDENTIAL
CONFIDENTIAL PROPERTY OF DANIELS MANUFACTURING CORP. NOT TO BE DISCLOSED TO
OTHERS. REPRODUCTION OR USED FOR ANY OTHER PURPOSE EXCEPT AS AUTHORIZED IN
WRITING BY DANIELS MANUFACTURING. MUST BE RETURNED TO DANIELS MANUFACTURING
CORP. ON COMPLETION OF ORDER OR PURPOSES FOR WHICH LENT.
HEAT TREAT
DRN.
JWS
CHK'D.
3/25/1986
DATE
TITLE
NOTE:
N/A
CREATED FROM AN INVENTOR MODEL.
CHANGES MUST BE REFLECTED IN THE 3D PART
FINISH
N/A
THIS DRAWING IS AN OUTLINE
DRAWING OF THE RESPECTIVE
DMC PART NUMBER
WHERE USED:
AF8
INDICATED. ACTUAL DMC
SIZE
SCALE
PART NUMBER IS CAD PART
NUMBER WITHOUT
THE "-ENV" SUFFIX
TURRET HEAD (M22520/1-14)
ENVELOPE DRAWING
CAD P/N
SHEET
TH286-ENV
DWG. NO.
1 OF 1
REV.
DO NOT SCALE DRAWING
B
2:1
TH286
2
