8
7
1.18
0.955
REF
6
5
4
3
2
1
1.10
0.13
F
2X
0.136
REF
A
C
L
F
1.580
1.203
C
L
0.079
0.640
REF
0.87
REF
1.10
REF
COVER
2X
0.13
0.136
4X R0.218
C
L
0.875
0.079
E
0.620
REF
REAR MOUNT
PANEL CUT-OUT
E
A
0.13
TYP
0.275
1.557
REF
0.14
3X
0.060
REF
0.13
HOUSING
0.275
0.65
0.60
1.557
C
L
RIGHT ANGLE
GROUND TERMINAL
0.275
0.778
D
2X
0.136 THRU HOLE
0.176 0.045
C
L
D
0.275
0.283
0.628
REF
0.283
REF
0.88
2X 0.136
MOUNTING HOLE
C
L
0.062 X 0.156
SLOT
3X
0.070±0.003
HOLE
PC BOARD LAYOUT
COMPONENT SIDE
C
3X 0.078 X 0.157
RIGHT ANGLE TERMINALS
0.79
C
L
C
0.48
SECTION A-A
PRODUCTION DATE CODE
(WEEK + YEAR)
NOTES:
1. MEETS IEC 60320 SPECIFICATION.
2. AGENCY APPROVAL & RATING:
VDE: 10A, 250V AC.
UL & CSA: 15A, 250V AC.
3. MATERIALS:
HOUSING AND COVER, BLACK THERMOPLASTIC.
TERMINALS, TIN PLATED COPPER ALLOY.
L
B
0.99
B
4. THIS PRODUCT IS RoHS COMPLIANT.
CUSTOMER DRAWING
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
UNLESS OTHERWISE SPECIFIED
SIZE
FINISH
WIDTH
MULT
LBS/M
MATERIAL
SPEC No.
TEMPER
A
1.05
1.580
REF
1.98
1. ALL DIMENSIONS IN INCHES
- TWO PLACE DECIMALS
- THREE PLACE DECIMALS
L
K
REV
0.02
0.005
SPEC No.
FIRST USED ON
DATE DRAWN
BY
CHKD
A
SCALE
3:1
26887
24129
ECO NUMBER
11/29/11
03/27/02
DATE
BL
BL
BY
TJK
TJK
APVD
05/05/89
TJK
REVISIONS
DO NOT SCALE DRAWING
NAME
MALE AC RECEPTACLE
RIGHT ANGLE PC MOUNT, RoHS
GHJ
05/09/89
RV
05/09/89
APVD
SHEET
PART No.
1
OF
1
REV
EAC333
