MKDSN 2,5/ 3 GY PA1,3 VPE1000 - 1706469
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB terminal block, Nominal current: 16 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 3,
Connection method: Screw connection with tension sleeve, Mounting: Wave soldering, Conductor/PCB
connection direction: 0 °, Color: gray
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
GTIN
Custom tariff number
Note
4046356861519
85369010
Made to Order (non-returnable)
1000 STK
1000 STK
Technical data
Dimensions
Length
Pitch
Dimension a
Constructional height
Length of the solder pin
Pin dimensions
Pin spacing
Hole diameter
9.5 mm
5.00 mm
10 mm
15 mm
3.5 mm
0,8 x 0,9 mm
5 mm
1.3 mm
General
Range of articles
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
MKDSN 2,5
4 kV
4 kV
4 kV
250 V
400 V
630 V
EN-VDE
16 A
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1706469
MKDSN 2,5/ 3 GY PA1,3 VPE1000 - 1706469
Technical data
General
Nominal cross section
Solder pin surface
Internal cylindrical gage
Stripping length
Number of positions
Screw thread
Tightening torque, min
Tightening torque max
2.5 mm²
Sn
A3
6.5 mm
3
M3
0.5 Nm
0.6 Nm
Connection data
Conductor cross section AWG min.
Conductor cross section AWG max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
24
14
0.2 mm²
0.75 mm²
0.2 mm²
0.75 mm²
0.25 mm²
0.75 mm²
0.5 mm²
1.5 mm²
Standards and Regulations
Connection in acc. with standard
EN-VDE
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Approvals
Approvals
Approvals
EAC
Ex Approvals
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1706469
MKDSN 2,5/ 3 GY PA1,3 VPE1000 - 1706469
Approvals
Approval details
EAC B.01742
