This document was generated on 11/28/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0738090205
Active
HDM® Backplane Connector System
HDM Board-to-Board Midplane Header, Vertical, Press-Fit, Closed End, Guide Post B
Location, C Polarization Key, 72 Circuits
Documents:
3D Model
Drawing (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Component Type
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Resin
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Data Rate
Real Signals (per 25mm)
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Packaging Specification PK-70873-0818 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
LR19980
E29179
Backplane Connectors
73809
Midplane
Shroud Housing
HDM® Backplane Connector System
HDM
800753278950
72
72
Black
250
No
94V-0
Yes
Yes
Stainless Steel
N/A
High Temperature Thermoplastic
12
Open Pin Field
6
Vertical
5.55mm
No
None
Tube
2.00mm
2.00mm
Yes
Yes
-55°C to +105°C
1.0A
1.0 Gbps
72
250V AC
EU ELV
Not Reviewed
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
Search Parts in this Series
73809 Series
Mates With
73632 HDM+ Board-to-Board Daughtercard
Receptacle. 73780 HDM Board-to-Board
Daughtercard Receptacle
