1771321 Overview

Pluggable Terminal Blocks SMSTBA2,5/5-G-5,08AU

1771321 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	PHOENIX CONTACT
Reach Compliance Code	compliant
Terminal and terminal strip types	STRIP TERMINAL BLOCK

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1771321

Printed-circuit board connector - SMSTBA 2,5/ 5-G-5,08 AU - 1771321

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Header, Nominal current: 12 A, Number of positions: 5, Pitch: 5.08 mm, Color: green, Contact surface: Gold,

Mounting: Wave soldering

Why buy this product

Gold-plated contacts ensure transfer quality remains stable over the long term

Maximum flexibility when it comes to device design – one header for connectors with different connection technologies

Well-known mounting principle allows worldwide use

Angled connection enables multi-row arrangement on the PCB

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4046356460675

85366990

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Pitch

Dimension a

Constructional height

Length of the solder pin

5.08 mm

20.32 mm

15 mm

3.5 mm

General

Range of articles

Rated voltage (III/3)

Connection in acc. with standard

Nominal current I

Color

Number of positions

SMSTBA 2,5/..-G

250 V

EN-VDE

12 A

green

Standards and Regulations

Connection in acc. with standard

EN-VDE

CSA

11/14/2016 Page 1 / 3
