This document was generated on 09/08/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
47392-0104
Active
External Serial ATA
1.27mm Pitch External Improved Metal-Shielded Serial ATA Plug, Through Hole, Right
Angle, 0.38µm Gold (Au) Plating, Unmated Height 7.70mm, Red, Staggered Plastic
Pegs, without Mylar, 7 Circuits, Lead-Free
Documents:
3D Model
Drawing (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
General
Product Family
Series
Application
Comments
Component Type
Electrical Model
Overview
Product Name
Type
UPC
I/O Connectors
47392
Wire-to-Board
Staggered Posts
Plug
Yes
External Serial ATA
External Serial ATA
N/A
800756716954
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Boot Color
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Ports
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Waterproof / Dustproof
N/A
7
7
Red
Plug
Yes
Yes
Copper Alloy
Gold
Tin
1
Right Angle
Yes
Yes
1.30mm
Tray
Front
1.27mm
1.27mm
0.381µm
1.270µm
Yes
Yes
1
No
-35°C to +85°C
Through Hole
No
Search Parts in this Series
47392Series
Mates With
68782 External Serial ATA Cable
Assemblies . 47078-0001 , 47078-1001 ,
47078-2001 , 47078-0003 , 47078-0004
Cable Connector for External Serial ATA
Electrical
Current - Maximum per Contact
Grounding to Panel
1.5A
All Panel Ground Tabs
