TSM2N7002E

60V N-Channel MOSFET

SOT-23

SOT-323

Pin Definition:

1. Gate

2. Source

3. Drain

PRODUCT SUMMARY

(V)

DS(on)

(Ω)

3 @ V

= 10V

4 @ V

= 4.5V

(mA)

300

200

Features

●

Low On-Resistance: 3Ω

Low Input and Output Leakage

Block Diagram

Application

●

Direct Logic-Level Interface: TTL/CMOS

Solid-State Relays

Ordering Information

Part No.

TSM2N7002ECX RF

TSM2N7002ECU RF

Package

SOT-23

SOT-323

Packing

3Kpcs / 7” Reel

N-Channel MOSFET

Absolute Maximum Rating

(Ta = 25

C unless otherwise noted)

Parameter

Drain-Source Voltage

Gate-Source Voltage

Continuous Drain Current

Pulsed Drain Current

Continuous Source Current (Diode Conduction)

Maximum Power Dissipation

Operating Junction Temperature

Operating Junction and Storage Temperature Range

a,b

Symbol

, T

STG

Ta = 25 C

Ta = 75 C

Limit

±20

300

350

220

+150

-55 to +150

Unit

Thermal Performance

Parameter

Lead Temperature (1/8” from case)

Junction to Ambient Thermal Resistance (PCB mounted)

Symbol

RӨ

Limit

357

Unit

C/W

Notes:

a. Pulse width limited by the Maximum junction temperature

b. Surface Mounted on FR4 Board, t

≤

5 sec.

c. The power dissipation of the package may result in a continuous drain current.

1/7

Version: A07
