This document was generated on 02/28/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0765605108
Active
Impact Backplane Connector and Cable Assembly System
Impact 100 Ohm 6 Pair RAM Right Angle Header, Right Guided, Open Endwall, 10
Columns, 180 Circuits, Pin Length 5.50mm, Plated Through Hole Dimension 0.39mm,
Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-76060-999-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Application Tooling Documents
Component Type
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Stackable
Temperature Range - Operating
Termination Interface: Style
Electrical
Packaging Specification PK-70873-777 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
E29179
Backplane Connectors
76560
Coplanar
TM-622018799
PCB Header
Impact Backplane Connector and Cable Assembly
System
Impact
884982480681
180
180
Black
200
No
94V-0
Yes
None
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
32.008/g
10
6
18
Right Angle
1.20mm
No
Yes
1.00mm
Tray
1.90mm
1.90mm
0.762µm
No
-55°C to +85°C
Through Hole - Compliant Pin
Search Parts in this Series
76560 Series
Mates With
76150 Impact 100 Ohm Daughtercard
Current - Maximum per Contact
Data Rate
Impedance
Shield Type
Shielded
Voltage - Maximum
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Electrical Model Document
Packaging Specification
Product Specification
S-Parameter Model
Sales Drawing
Symbol/Footprint Data
0.75A
25.0 Gbps
100Ω
N/A
No
30V AC (RMS)/DC
N/A
EE-76560-0001
PK-70873-777
PS-76060-999-001
SP-76560-0001, SP-76560-002
SD-76560-9004
SYM-76560-5108
