Blade Terminal & Special Purpose Fuses
Low Voltage
RoHS
MIDI
®
FUSE
®
The MIDI
®
Fuse offers a bolt-on space saving fuse for high current wiring
protection and provides time delay characteristics with “Diffusion Pill
Technology”. The MIDI Fuse was designed and patented by Littelfuse.
ELECTRICAL CHARACTERISTICS:
% of Ampere
Rating
100%
110%
150%
200%
300%
Ampere
Rating
30-125A
30-125A
30-125A
30-125A
150-200A
30-125A
150-200A
Opening Time
100 hours,
Minimum
4 hours,
Minimum
90 sec.,
Min.;
3600 sec.,
Max.
5 sec.,
Min.;
100 sec.,
Max.
1 sec.,
Min.;
15 sec.,
Max.
.5 sec.,
Min.;
15 sec.,
Max.
.3 sec.,
Min.;
3 sec.,
Max.
AGENCY APPROVALS:
Recognized under the components program
of Underwriters Laboratories.
AGENCY FILE NUMBERS:
E71611
INTERRUPTING RATINGS:
1000 amperes at 32 VDC
VOLTAGE RATINGS:
32 VDC
AMBIENT TEMP.:
–40°C to +125°C
PATENTED
INTERRUPTING RATING:
1000A @ 32 VDC
41
12
16
30
5.5
ORDERING INFORMATION:
Catalog
Number
0498
030
0498
040
0498
050
0498
060
0498
070
0498
080
0498
100
0498
125
0498
150
0498
200
Ampere
Rating
30
40
50
60
70
80
100
125
150
200
Voltage
Rating (VDC)
32
32
32
32
32
32
32
32
32
32
Nominal Cold
Resistance (mΩ)
2.1
1.3
1.04
0.87
0.72
0.56
0.45
0.40
0.33
0.25
8.0 (30-80A)
0.4
4
8.3 (100-200A)
30A
40A
50A
60A
70A
80A
100A
125A
150A
200A
Average Time Current Curves
1000
100
MIDI
®
FUSE
Fuseholders
SPECIFICATIONS:
Electrical:
Use with MIDI
®
Fuses from 30 to 200 amps. (32V)
Body:
Glass Filled Thermoplastic
Body Color:
Black
Cover With Tether:
Glass Filled Thermoplastic
Cover Color:
Black
Ambient Temp.:
–
40°C to +125°C
Fuse Mounting:
M5 Threaded Stud and Hex Nuts
51.35
Cable Positions:
Optional
(2.022)
Side Stackable Feature
15.2
(.60)
TIME IN SECONDS
ORDERING INFORMATION:
Catalog Number 498900.
10
1
0.1
3.8
(.15)
(2 Holes)
0.01
41.0
(1.61)
456
10
100
1000
10000
CURRENT IN AMPERES
