MIC5331-MNYMT-TR

Description
LDO Regulator Pos 2.8V2.85V 0.3A/0.3A 8-Pin TDFN EP T/R
File Size268KB，10 Pages
ManufacturerMicrochip
Websitehttps://www.microchip.com
Environmental Compliance
Download Datasheet Parametric Compare View All

MIC5331-MNYMT-TR Online Shopping

Suppliers Part Number Price MOQ In stock
MIC5331-MNYMT-TR - - View Buy Now

MIC5331-MNYMT-TR Overview

LDO Regulator Pos 2.8V2.85V 0.3A/0.3A 8-Pin TDFN EP T/R

MIC5331-MNYMT-TR Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
HTS8542.39.00.01
TypeLDO
Number of Outputs2
PolarityPositive
Accuracy (%)±1
Output TypeFixed
Output Voltage (V)2.8|2.85
Maximum Output Current (A)0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3|0.3
Minimum Input Voltage (V)2.3
Maximum Input Voltage (V)5.5
Maximum Dropout Voltage @ Current (V)0.24@300mA|0.04@50mA
Line Regulation0.3%/V
Load Regulation0.5%
Typical Ground Current @ Full Load (mA)0.04
Junction to Ambient90°C/W
Special FeaturesCurrent Limit|Thermal Shutdown Protection
Minimum Operating Temperature (°C)-40
Maximum Operating Temperature (°C)125
PackagingTape and Reel
Supplier PackageTDFN EP
Pin Count8
MountingSurface Mount
Package Height0.55(Max)
Package Length2
Package Width2
PCB changed8

Preview

Download Datasheet
MIC5331
Micro-Power High Performance
Dual 300mA ULDO™
General Description
The MIC5331 is a tiny dual low quiescent current LDO
ideal for applications that are power sensitive. The
MIC5331 integrates two high performance, 300mA LDOs
into a tiny 2mm x 2mm Thin MLF
®
package, which
occupies less PC board area than a single SOT-23
package.
The MIC5331 is designed to reject input noise and provide
low output noise with fast transient response to any load
change quickly even though it is a low quiescent current
part. This combination of PSRR, low noise and transient
response along with low power consumption makes for a
very high performance, yet general purpose product.
The MIC5331 is a µCap design, operating with very small
ceramic output capacitors, which reduces required board
space and component cost; and it is available in fixed
output voltages in the tiny 8-pin 2mm x 2mm Thin MLF
®
leadless package.
Data sheets and support documentation can be found on
Micrel’s web site at: www.micrel.com.
Features
•
•
•
•
•
•
•
•
•
•
2.3V to 5.5V input voltage range
300mA output current per LDO
Very low quiescent current: 25µA per LDO
High PSRR - >65dB on each LDO
Stable with 1µF ceramic output capacitors
Tiny 8-pin 2mm x 2mm Thin MLF
®
package
Ultra-low dropout voltage – 120mV @ 300mA
Low output voltage noise – 50µVrms
Thermal shutdown protection
Current limit protection
Applications
•
•
•
•
•
Camera phones
Mobile phones
PDAs
GPS receivers
Portable devices
___________________________________________________________________________________________________________
Typical Application
MIC5331-xxYMT
VIN
EN1
VBAT
1µF
EN2
GND
VOUT1
VOUT2
1µF
1µF
I/O
CORE
Camera DSP
Camera DSP Power Supply Circuit
ULDO is a trademark of Micrel, Inc.
MLF and
MicroLeadFrame
are registered trademarks of Amkor Technology, Inc.
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (
408
) 944-0800 • fax + 1 (408) 474-1000 • http://www.micrel.com
February 2008
M9999-021408-A
