P0300SCMCLRP

Description
Sidacs 500A 25V 25-45pF
CategoryAnalog mixed-signal IC    Trigger device
File Size897KB,4 Pages
ManufacturerLittelfuse
Websitehttp://www.littelfuse.com
Environmental Compliance
Download Datasheet Parametric View All

P0300SCMCLRP Online Shopping

Suppliers Part Number Price MOQ In stock
P0300SCMCLRP - - View Buy Now

P0300SCMCLRP Overview

Sidacs 500A 25V 25-45pF

P0300SCMCLRP Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Parts packaging codeDO-214AA
package instructionSMALL OUTLINE, R-PDSO-C2
Contacts2
Reach Compliance Codenot_compliant
Other featuresUL RECOGNIZED
Maximum breakover voltage40 V
ConfigurationSINGLE
Maximum off-state DC voltage25 V
Maximum holding current50 mA
JEDEC-95 codeDO-214AA
JESD-30 codeR-PDSO-C2
JESD-609 codee3
Humidity sensitivity level1
On-state non-repetitive peak current30 A
Number of components1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
surface mountYES
Terminal surfaceMatte Tin (Sn)
Terminal formC BEND
Terminal locationDUAL
Maximum time at peak reflow temperature30
Trigger device typeSILICON SURGE PROTECTOR
Base Number Matches1
Broadband Optimized
TM
Protection
SIDACtor
®
Protection Thyristors
MC Series - DO-214
Description
RoHS
Pb
e3
The MC Series DO-214 are low capacitance SIDACtor
®
components designed to protect broadband equipment
such as VOIP DSL modems and DSLAMs from damaging
,
overvoltage transients.
The series provides a surface mount solution that enables
equipment to comply with global regulatory standards
while limiting the impact to broadband signals.
Features and Benefits
Low voltage overshoot
Low on-state voltage
Does not degrade surge
Agency Approvals
Agency
Agency File Number
E133083
capability after multiple
surge events within limit.
RoHS Compliant and
Halogen-Free
Pb-free E3 means 2nd level
40% lower capacitance
interconnect is Pb-free and
the terminal finish material
is tin(Sn) (IPC/JEDEC J-STD-
609A.01)
surged in excess of ratings
than our Baseband
Protectors, for applications
that demand greater signal
integrity
Fails short circuit when
Pinout Designation
NOT APPLICABLE
Schematic Symbol
Applicable Global Standards
TIA-968-A
TIA-968-B
ITU K.20/21/45 Enhanced Level*
ITU K.20/21/45 Basic Level
GR 1089 Inter-building*
GR 1089 Intra-building
IEC 61000-4-5 2nd edition
YD/T 1082
YD/T 993
YD/T 950
*A-rated parts require series resistance
Electrical Characteristics
Part Number
P0080SAMCLRP
P0220SAMCLRP
P0300SAMCLRP
P0080SCMCLRP
P0220SCMCLRP
P0300SCMCLRP
P0640SCMCLRP
P0720SCMCLRP
P0900SCMCLRP
P1100SCMCLRP
P1300SCMCLRP
P1500SCMCLRP
P1800SCMCLRP
P2100SCMCLRP
P2300SCMCLRP
P2600SCMCLRP
P3100SCMCLRP
P3500SCMCLRP
P4500SCMCLRP
Marking
P-8AM
P02AM
P03AM
P-8CM
P02CM
P03CM
P06CM
P07CM
P09CM
P11CM
P13CM
P15CM
P18CM
P21CM
P23CM
P26CM
P31CM
P35CM
P45CM
V
DRM
@l
DRM
=5µA
V min
6
15
25
6
15
25
58
65
75
90
120
140
170
180
190
220
275
320
400
V
S
@100V/µs
V max
25
32
40
25
32
40
77
88
98
130
160
180
220
240
260
300
350
400
530
I
H
mA min
50
50
50
50
50
50
150
150
150
150
150
150
150
150
150
150
150
150
50
I
S
mA max
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
I
T
A max
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
V
T
@I
T
=2.2 Amps
V max
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
Capacitance
@1MHz, 2V bias
pF min
10
10
10
25
25
15
50
50
40
40
35
30
30
30
30
30
30
25
25
pF max
35
35
35
60
60
40
80
75
70
70
60
55
50
50
50
45
45
50
45
Notes:
- Absolute maximum ratings measured at T
A
= 25ºC (unless otherwise noted).
- Components are bi-directional.
© 2017 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 02/23/17
