1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0118
General Information
76650-0118
Part Number:
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
SEARAY Connector Kit
High Density Mezz Interconnect Plug and Receptacle
SEARAY*
(Molex Parts within this kit) - EU and China RoHS Compliant, UL and CSA
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Product Highlights
The SEARAY board-to-board connector is designed for computer, networking,
telecom, storage and general market applications with high pin-count devices or
memory modules that are mounted on mezzanine or module PC Boards (PCBs).
The design of our SEARAY has superior electrical and mechanical features that are
cost competitive. The unique, Molex-patented, solder charge technology results in
better process yields and a lower applied cost versus equivalent BGA connector
products. Circuit sizes range from 160 through 500 positions, and mated stack
heights cover 7mm (.276") to 13mm (.512").
Features and Benefits
• Unique patented solder attach is more
cost effective and reliable than BGA
• SEARAY footprint is compatible with other
1.27mm(.050") by 1.27mm(.050") products
• Robust guidance and polarization aligns
connectors to mate in correct position
*SEARAY is a trademark of Samtec, Inc.
Board-to-Board
1.27mm (.050") by 1.27mm (.050") Pitch
Receptacle and Plug
Vertical
200, 300, and 400
2.7 Amps
240 Volts
Applications
• High and Mid-Range Computers and Servers
• Medical Scanning Equipment
• Military
• Network Routers and Switches
• Mobile Base Stations
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0118
Bill of Materials for Part No. 76650-0118
Country
Molex Part No. of Origin
45970-2311
45970-3211
45970-4311
USA
USA
USA
Description
1.27mm (.050") x 1.27mm (.050") Pitch SEARAY* Plug, 200
Circuits, 6.10mm (.240") Unmated Height, 10 Rows
1.27mm (.050") x 1.27mm (.050") Pitch SEARAY* Plug, 300
Circuits, 5.59mm (.220") Unmated Height, 10 Rows
1.27mm (.050") x 1.27mm (.050") Pitch SEARAY* Plug, 400
Circuits, 6.10mm (.240") Unmated Height, 10 Rows
1.27mm (.050") by 1.27mm (.050") Pitch SEARAY*
Receptacle, 200 Circuits, 6.55mm (.258") Unmated Height,
10 Rows
1.27mm (.050") by 1.27mm (.050") Pitch SEARAY*
Receptacle, 300 Circuits, 5.05mm (.199") Unmated Height,
10 Rows
Quantity in
Kit
1
1
1
45971-2311
USA
1
45971-3111
USA
1
*SEARAY is a trademark of Samtec, Inc.
No Recommended Molex Tool for Part No. 76650-0118
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 2 of 2
