STEVAL-ILL032V1
Multicolor LED matrix demonstration board
based on the STP24DP05BTR
Data brief
Features
■
■
■
4 STP24DP05BTR drivers for each display
panel
8 panels can be cascaded in series using a flat
ribbon cable
RoHS compliant
Description
The STEVAL-ILL032V1 is a demonstration board
featuring the STP24DP05BTR RGB LED driver to
drive the RGB LED matrix panel.
The STEVAL-ILL032V1 demonstration board is
part of a complete system which includes at least
one control board (STEVAL-ILL033V1) and one
RGB LED matrix display panel.
October 2011
Doc ID 022349 Rev 1
1/5
www.st.com
