AK6 Overview

6000 W, BIDIRECTIONAL, SILICON, TVS DIODE

Preview

Download Datasheet

View All

Transient Voltage Suppression Diodes

Axial Leaded – 6kA > AK6 series

AK6 Series

Description

RoHS

The AK6 series of high power TVS diode is specially

designed for meeting severe surge test environment of

both AC and DC line protection applications. It features a

very fast response and ultra low clamping characteristics

over traditional metal oxide ( MOV ) solutions. They can be

connected in series and / or parallel to create a very high

surge current protection solution.

Agency Approvals

AGENCY

AGENCY FILE NUMBER

E128662

Features

• Very low clamping voltage

• Ultra compact: less

than one-tenth the size

of traditional discrete

solutions

• Sharp breakdown voltage

• Low slope resistance

• Bi-directional

• Foldbak technology for

superior clamping factor

• Symmetric in leads width

for easier soldering

during assembly.

• IEC-61000-4-2 ESD

15kV(Air), 8kV (Contact)

• ESD protection of data

lines in accordance with

IEC 61000-4-2

• EFT protection of data

lines in accordance with

IEC 61000-4-4

• Halogen-free

• RoHS compliant

• Glass passivated junction

• Pb-free E4 means 2nd

level interconnect is

Pb-free and the terminal

finish material is silver

Maximum Ratings and Thermal Characteristics

=25

C unless otherwise noted)

Parameter

Operating Storage Temperature

Range

Operating Junction Temperature

Range

Current Rating

Note:

1. Rated I

measured with 8/20μS pulse.

Symbol

STG

Value

-55 to 150

-55 to 125

Unit

°C

ºC

Functional Diagram

Additional Infomarion

Bi-direcctional

Datasheet

Resources

Samples

Electrical Characteristics

(T =25°C unless otherwise noted)

Part

Numbers

AK6 - 030C

AK6 - 058C

AK6 - 066C

AK6 - 076C

AK6 - 170C

AK6 - 190C

AK6 - 240C

AK6 - 380C

AK6 - 430C

Max. Clamping

Max.

Max. Temp

Test

Max.

Typical Reverse Breakdown

Standoff

Agency

Voltage

Reverse

Coefficient Capacitance Approval

Current

Part

Voltage

Voltage (V

) @ I

@ I

Peak Pulse

Leakage

OF V

0 Bias 10kHz

Marking

)

Current (I

) (Note 1)

) @V

Volts

(µA)

µA

Min Volts Max Volts (mA)

Volts I

Amps

(%/

(nF)

6 - 030C

6 - 058C

6 - 066C

6 - 076C

6 - 170C

6 - 190C

6 - 240C

6 - 380C

6 - 430C

170

190

240

380

430

180

200

250

401

440

220

245

285

443

490

110

120

140

260

290

340

520

625

6,000

0.1

11.0

8.0

6.0

6.5

2.8

2.5

2.0

1.4

1.0

Note:

Using 8/20µS wave shape as defined in IEC 61000-4-5.

Specifications are subject to change without notice.

Revised: 11/20/15

AK6 Related Products

	AK6	AK6-170C	AK6-380C	AK6-076C-12	AK6-066C
Description	6000 W, BIDIRECTIONAL, SILICON, TVS DIODE	6000 W, BIDIRECTIONAL, SILICON, TVS DIODE	6000 W, BIDIRECTIONAL, SILICON, TVS DIODE	TVS DIODE 76V 140V AXIAL	反向关断电压（典型值）：66V 击穿电压（最小值）：72V 极性：- 箝位电压：120V 峰值脉冲电流（10/1000us）：6000A (8/20us)
Is it Rohs certified?	-	conform to	conform to	-	conform to
Maker	-	Littelfuse	Littelfuse	-	Littelfuse
Reach Compliance Code	-	unknow	unknow	unknown	unknown
ECCN code	-	EAR99	EAR99	EAR99	EAR99
Other features	-	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED
Maximum breakdown voltage	-	220 V	443 V	95 V	80 V
Minimum breakdown voltage	-	180 V	401 V	85 V	72 V
Breakdown voltage nominal value	-	200 V	422 V	-	76 V
Maximum clamping voltage	-	260 V	520 V	-	120 V
Configuration	-	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	-	SILICON	SILICON	SILICON	SILICON
Diode type	-	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE
Number of components	-	1	1	1	1
Number of terminals	-	2	2	2	2
Maximum operating temperature	-	150 °C	150 °C	125 °C	125 °C
Minimum operating temperature	-	-55 °C	-55 °C	-55 °C	-55 °C
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
polarity	-	BIDIRECTIONAL	BIDIRECTIONAL	BIDIRECTIONAL	BIDIRECTIONAL
Maximum repetitive peak reverse voltage	-	170 V	380 V	76 V	66 V
surface mount	-	NO	NO	NO	NO
technology	-	AVALANCHE	AVALANCHE	AVALANCHE	AVALANCHE
Terminal form	-	WIRE	WIRE	THROUGH-HOLE	THROUGH-HOLE
