Type 4 Mild Steel Wallmount Enclosure w/ Window
Eclipse Series
Hinge Door with Quarter Turn
Application
Designed to enclose electrical and/or electronic equipment in wallmount applications
where viewing of component operation is necessary while maintaining protection ratings.
Impressive styling features like hidden hinges, attractive latching systems make the
Eclipse a suitable addition to any high-tech equipment installation.
A wide range of sizes and practical accessories make this product line a complete
package.
Standards
UL 508A Type 3R, 4 and 12
CSA Type 3R, 4 and 12
Complies with
NEMA 3R, 4 and 12
IEC 60529, IP66
Construction
Formed 14 or 16 gauge steel.
Full view UV resistant polycarbonate window allow maximum viewing area of inner panel.
Smooth, continuously welded seams ground smooth.
Door stiffeners are provided where required for increased strength and rigidity - designed
to also permit additional mounting options.
Formed lip on enclosure to exclude flowing liquids and contaminants.
Door latches feature the added safety of quarter turn slot requiring use of tool for opening
Doors may be easily removed for modifications and are interchangeable.
Seamless poured-in place gasket.
Collar studs provided for mounting inner panel.
Includes hardware kit with panel mounting nuts and sealing washers for wall mounting
holes.
Bonding stud provided on door and grounding stud installed in enclosure.
Hinges are constructed from 304 stainless steel.
Hinge pins are stainless steel.
Quarter turn latches are zinc diecast with black epoxy finish.
Finish
Cover and enclosure are phosphatized and finished with a recoatable powder inside and
out with choice of ANSI 61 smooth Gray (GY) or RAL7035 textured light gray (LG).
Accessories
Climate Control
Ventilation
DIN Rail Mounting Kit
Drip Shield Kit
Gland Plates
https://www.hammfg.com/electrical/products/industrial/en4sdw
Blowers and Fans
DIN Rails
Door Stop Kit
Filtered Fans
Heaters
1/3
5/9/2018
Type 4 Mild Steel Wallmount Enclosure w/ Window (Eclipse Series) - Hammond Mfg.
Handles
Literature Pocket
Mounting Foot Kit
Swing Frame
Rear Hole Plugs
Quarter Turn Assemblies
Type 4 Hardware Kits
Padlock Adaptor
Inner Panels
Quarter Turn Inserts and Keys
Swing Panel
Eclipse Rack Panel
Replacement Hinge Pins
Temperature Controls and Accessories
Touch-Up Spray Paint
Ground Wire Kits
Part No.
(ANSI 61 Gray)
EN4SD16126WGY
EN4SD20166WGY
EN4SD20206WGY
EN4SD24206WGY
EN4SD24246WGY
EN4SD16128WGY
EN4SD20168WGY
EN4SD20208WGY
EN4SD24208WGY
EN4SD24248WGY
EN4SD30248WGY
Part No.
(RAL7035 Light Gray)
EN4SD16126WLG
EN4SD20166WLG
EN4SD20206WLG
EN4SD24206WLG
EN4SD24246WLG
EN4SD16128WLG
EN4SD20168WLG
EN4SD20208WLG
EN4SD24208WLG
EN4SD24248WLG
EN4SD30248WLG
Overall Dimensions Door/Body Latch¹ Hinge
A
B
C
6.00
6.00
6.00
6.00
6.00
8.00
8.00
8.00
8.00
8.00
8.00
Gauge
16
16
16
16
14
16
16
16
16
14
14
16
16
14
14
14
14
14
Qty
1
1
1
1
2
1
1
1
1
2
2
1
1
2
2
2
2
2
Qty
2
2
2
2
2
2
2
2
2
2
3
2
2
2
3
2
2
3
F
16.00 12.00
20.00 16.00
20.00 20.00
24.00 20.00
24.00 24.00
16.00 12.00
20.00 16.00
20.00 20.00
24.00 20.00
24.00 24.00
30.00 24.00
Viewing Area Optional Panel Inner Panel Dimensions
G
H
6.71
Part No.
EP1612
EP2016
EP2020
EP2420
EP2424
EP1612
EP2016
EP2020
EP2420
EP2424
EP3024
EP2020
EP2420
EP2424
EP3024
EP2424
EP2424
EP3024
D
14.20
18.20
18.20
22.20
22.20
14.20
18.20
18.20
22.20
22.20
28.20
18.20
22.20
22.20
28.20
22.20
22.20
28.20
E
10.20
14.20
18.20
18.20
22.20
10.20
14.20
18.20
18.20
22.20
22.20
18.20
18.20
22.20
22.20
22.20
22.20
22.20
10.00 11.33
14.00 15.33 10.71
14.00 15.33 14.71
18.00 19.33 14.71
18.00 19.33 16.15
10.00 11.33
6.71
14.00 15.33 10.71
14.00 15.33 14.71
18.00 19.33 14.71
18.00 19.33 16.15
12.00 25.33 16.15
18.00 15.33 14.71
18.00 19.33 14.71
18.00 19.33 16.15
12.00 25.33 16.15
18.00 19.33 16.15
18.00 19.33 16.15
12.00 25.33 16.15
EN4SD202012WGY EN4SD202012WLG
EN4SD242012WGY EN4SD242012WLG
EN4SD242412WGY EN4SD242412WLG
EN4SD302412WGY EN4SD302412WLG
EN4SD242416WGY EN4SD242416WLG
EN4SD242420WGY EN4SD242420WLG
EN4SD302420WGY EN4SD302420WLG
¹ All Window Door latch types are quarter turns.
20.00 20.00 12.00
24.00 20.00 12.00
24.00 24.00 12.00
30.00 24.00 12.00
24.00 24.00 16.00
24.00 24.00 20.00
30.00 24.00 20.00
Data subject to change without notice
https://www.hammfg.com/electrical/products/industrial/en4sdw
