SMT High Current Inductors
Features
•
Compact Design for easy SMT
LP06 Series
Applications
•
Power Supply Modules
•
Notebook Computers
•
Servers
Mounting
•
Robust Design for High Current DC/
DC Applications
• Magnetically Shielded for Reduced
EMI
Packaging:
Reel Diameter: 13”, Reel Width: 24 mm, Pieces/Reel: 600
Mechanical
13.8 max
Recommended PCB layout
3.5
2.5
Schematic
1
3.2
2.60
1
5.5 max
Top View
Electrical Specifications
Part Number
LP06-101
LP06-181
LP06-221
LP06-271
LP06-331
LP06-391
LP06-471
LP06-561
LP06-681
LP06-821
LP06-102
LP06-222
LP06-332
LP06-422
LP06-472
LP06-562
LP06-722
Specifications subject to change without notice.
LP06-XXX
YYWW
(nH, nom.)
Inductance
1
100
180
220
270
330
390
470
560
680
820
1000
2200
3300
4200
4700
5600
7200
13.5
max
7.2
3
5.20
2
2
2.60
12.0
TOP VIEW
Side View
Top View
units: mm
DCR
(mΩ)
I
dc
5
(A)
I
sat
6
(A)
0.5
1
1
1
1
1.9
1.9
2.5
2.5
3.9
3.9
4.6
6.3
7.1
7.1
10
12
45
35
35
35
35
25
25
22
22
17
17
14
12
10.5
9.5
9.5
8
75
65
60
55
48
45
42
40
35
32
28
15
12
11
10
8
7
1. Tested at 1MHz, 0.1Vrms.
2. Electrical specifications at 25ºC.
3. Operating range: -40ºC to +130ºC.
This is a combination of ambient
plus temperature rise.
4. Meets UL 94V-0.
5. Idc is the DC current required to
produce a temperature rise of 40ºC
at an ambient temperature of 25ºC.
6. Isat is the DC current required to
reduce the nominal inductance by
10%.
7. Inductance tolerance is +/-10%.
(10/06) LP06-1
