Preliminary
HEAT SINKS
FOR LEDs
JTI – HEAT SINKS FOR POWER LEDs
882 SERIES – RADIAL FIN HEAT SINK FOR “STAR” LED PACKAGES
Wakefield's new 882 series heat sinks can be used with LEDs in the
star package from Lumileds, Osram, and others. The radial design and
fin area is ideally suited for natural convection applications such as
ceiling lighting. A fan can also be used for increased performance in a
forced convection application. Three sets of mounting holes allow
maximum flexibility.
•
•
•
The six .090 holes accommodate the LED module with # 4-40
screws,
The six .153 holes can accommodate a multi-LED circuit
board, mount to a panel with # 10-32 screws, or act as a
conduit for wires
The four .201 holes can be used to mount the heat sink to a
panel with # 1/4-20 screws
Standard
P/N
882-50AB
882-100AB
882-200AB
882-300AB
Height “A”
in (mm)
0.50 (12.7)
1.00 (25.4)
2.00 (50.8)
3.00 (76.2)
Natural Convection
Temp rise over ambient
Forced Convection
Thermal resistance @200LFM
Weight
lbs (grams)
0.073 (34)
0.146 (67)
0.293 (133)
0.439 (199)
60
0
C @ 9 W
48
0
C @ 9 W
36
0
C @ 9 W
28
0
C @ 9 W
4.33
2.88
1.89
1.55
0
C/W
0
C/W
0
C/W
0
C/W
MECHANICAL DIMENSIONS
NATURAL AND FORCED
CONVECTION CHARACTERISTICS
882 SERIES THERMAL PERFORMANCE
AIR VELOCITY (LFM)
0
100
TEMPERATURE RISE OVER AMBIENT (
o
C)
200
400
600
800
1000
5
4
3
2
1
0
THERMAL RESISTANCE
SINK-TO-AMBIENT (
o
C/w)
80
60
40
20
0
0
3
6
9
12
15
POWER (WATTS)
Wakefield Thermal Solutions believes that information provided is accurate as of publication date. Product testing in customer applications is
recommended. The physical properties reported are representative of performance values obtained by standard predictive and testing methods.
Wakefield Thermal Solutions is a manufacturer of heat dissipation products and reserves the right to make changes to its products without notice to
improve the design or performance characteristics.
Tel. (603) 635-2800
Fax. (603) 635-1900
www.wakefield.com
33 Bridge Street
Pelham NH, 03076
MARCH 2008
