BFB
97 x 94 x 33 MM SERIES
DRAWING
32.9±0.5
(1.295±0.020)
96.6±1.0
(3.803±0.039)
49.7±0.5
39.3±0.5
(1.957±0.020) (1.547±0.020)
38.6±0.3
(1.520±0.012)
300.0±10.0
31.7±0.3
(1.248±0.012)
Ø52.0
(Ø2.047)
■
DIMENSIONS
2.0±0.5
(0.079±0.020)
(2.267±0.020)
50.6±0.5
(1.992±0.020)
28.9
(1.138)
2.0±0.5
(0.079±0.020)
32.4±0.3
51.6±0.3
(1.276±0.012) (2.031±0.012)
57.6±0.5
94.3±1.0
(3.713±0.039)
10.0
(0.394)
5.0±0.5
(0.197±0.020)
(11.811±0.394)
2-Ø4.5±0.3
Air Pressure
*
Bearing Type
Ball Bearings
*
Material
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
*
UL 1007 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
*
Weight : 180g (6.35 oz)
(2-Ø0.177±0.012)
UNIT :
mm
(INCH)
■
P
& Q CURVE
(AT RATED VOLTAGE)
96.0
80.0
64.0
48.0
32.0
16.0
0
(mm H
2
O)
0
0
0.3
12.0
0.6
24.0
Air Flow
0.9
36.0
1.2
1.5 (M
3
/MIN)
(CFM)
BFB1012X-C
EH
3.84
3.2
2.56
1.92
1.28
0.64
0
(IN H
2
O)
48.0
MODEL
PART NO.
BFB1012EH
REV. FUNCTION
-C
-R00/-F00
Rated
Voltage
VDC
12
Operating
Voltage
Range
VDC
7.0 to 12.6
Input
Current
Amp
1.97
Input
Power
Watt
23.64
Speed
R.P.M.
5800
Maximum
Air Flow
m
3
/min
1.288
CFM
45.49
Maximum
Air Pressure
mmH
2
O
93.83
IN H
2
O
3.694
Noise
dB-A
62.0
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
132
http://www.deltaww.com
BFB
97 x 94 x 33 MM SERIES
DRAWING
■
DIMENSIONS
Air Pressure
*
Bearing Type
Ball Bearings
*
Material
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
*
UL 1007 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
*
Weight : 166g (5.85 oz)
UNIT :
mm
(INCH)
■
P
& Q CURVE
(AT RATED VOLTAGE)
72.0
60.0
48.0
36.0
24.0
12.0
0
(mm H O)
2
2.88
2.4
1.92
1.44
0.96
0.48
0
(IN H O)
2
BFB1012X-A
M
L
0
0
0.3
12.0
0.6
24.0
0.9
36.0
1.2
3
1.5
(M /MIN)
48.0
(CFM)
Air Flow
MODEL
PART NO.
BFB1012L
BFB1012M
REV. FUNCTION
-A
-A
R00/F00
R00/F00
Rated
Voltage
VDC
12
12
Operating
Voltage
Range
VDC
4.0 to 13.2
4.0 to 13.2
Input
Current
Amp
0.37
0.55
Input
Power
Watt
4.44
6.60
Speed
R.P.M.
2700
3200
Maximum
Air Flow
m
3
/min
0.656
0.777
CFM
23.17
27.44
Maximum
Air Pressure
mmH
2
O
14.85
22.68
IN H
2
O
0.585
0.893
Noise
dB-A
49.5
52.5
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
133
http://www.deltaww.com
BFB
97 x 94 x 33 MM SERIES
DRAWING
1.85±0.5
(0.073±0.020)
50.0±0.5
(1.969±0.020)
(1.299±0.020)
29.3
(1.154)
33.0±0.5
94.4 ±1.0
(3.717 ±0.039 )
52.4±0.3
(2.063±0.012)
32.0±0.3
(1.260±0.012)
97.2 ±1.0
(3.827 ±0.039 )
39.0±0.3
(1.535±0.012)
1.85±0.5
(0.073±0.020)
■
DIMENSIONS
57.9±0.5
( 2.280±0.020)
10.0
(0.394)
325.0±10.0
(12.795±0.394)
2-Ø4.5±0.3
(2-Ø0.177±0.012)
32.0±0.3
(1.260±0.012)
Ø58.9
(Ø2.319)
mm
(INCH)
Air Pressure
*
Bearing Type
Ball Bearings
*
Material
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
*
UL 1007 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
*
Weight : 180g (6.35 oz)
UNIT :
■
P
& Q CURVE
(AT RATED VOLTAGE)
72.0
60.0
48.0
36.0
24.0
12.0
0
(mm H O)
2
2.88
2.4
1.92
1.44
0.96
0.48
0
(IN H O)
2
BFB1012/24X-A
EH
SH
VH
HH
0
0
0.3
12.0
0.6
24.0
0.9
36.0
1.2
1.5
(M
3
/MIN)
(CFM)
48.0
Air Flow
MODEL
PART NO.
BFB1012HH
BFB1012VH
BFB1012SH
BFB1012EH
REV. FUNCTION
-A
-A
-A
-A
R00/F00
R00/F00
R00/F00
R00/F00
Rated
Voltage
VDC
12
12
12
12
Operating
Voltage
Range
VDC
7.0 to 13.2
7.0 to 13.2
7.0 to 12.6
7.0 to 12.6
Input
Current
Amp
1.25
1.50
2.00
2.45
Input
Power
Watt
15.00
18.00
24.00
29.40
Speed
R.P.M.
4000
4500
5000
5300
Maximum
Air Flow
m
3
/min
0.971
1.075
1.179
1.302
CFM
34.28
37.97
41.65
46.00
Maximum
Air Pressure
mmH
2
O
39.70
49.58
64.23
71.48
IN H
2
O
1.564
1.952
2.529
2.814
39.0±0.3
(1.535±0.012)
Noise
dB-A
57.0
60.0
63.0
64.0
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
134
http://www.deltaww.com
