PHYSICAL DIMENSIONS:
∅0.188
REVISION
REV.
B
C
DESCRIPTION
RoHS Compliancy
Updated Operatiing Temperature
DATE
06-01-06
01-09-09
APPROVED
DP
LY
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC..........................................5 A RMS MAX
B. @ 250 VAC.........................................5 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.25 mA MAX
B. @ 250 VAC 50Hz.............................0.45 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
/
/
.05
/
/
.10
/
/
.15
15
6
.50
30
15
1.0
38
20
5.0
45
40
10
45
45
30
40
45
2
2.13 ± 0.02
1.77 MAX
BLUE
BLUE
4
1-3.
5
G/Y
2.52 MAX
1-4.
1
BROWN
BROWN
3
1-5.
1-6.
FREQ. MHz
1.33 MAX
4.0MIN
4.0MIN
COM. MODE dB
DIF. MODE dB
1-7.
OPERATING TEMPERATURE.................-25° TO +100° C
SAFETY:
RoHS COMPLIANT
0.79 MAX
1-8.
1-9.
SCHEMATIC:
Dim
range
(mm)
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
851-05/006
EMI FILTER
UNIT: in
L: 2.9mH
C1: 0.1uF
C2: 3300pF
0-1
1-6
6-18
18-50
50-120
120-250
250-500
REV. C
Approved / Date
JJH / 01-17-03
Drawn / Date
B.ZHANG
01-17-03
Checked / Date
01-17-03
