Pulse Transformers
https://www.schurter.com /PG85
IL
Cost optimized pulse transformers for THT mounting
Approvals and Compliances
Description
- High insulation rating (>2.2 kVAC) between the primary and the secon-
dary windings
- Small coupling capacitances between primary and secondary windings
limit transient feedback from the power supply side to the control elec-
tronics
- Cost optimized design
- The defined partial discharge voltage guarantees an effecively unlimited
serviceable live
Applications
- Galvanic separation of drive- and power-circuit
- Mainly used in ignition circuits with Thyristors, Triacs, power transistors
and IGBT's
- DC/DC converters
- Line coupling transformers in high speed data transmission
Weblinks
pdf datasheet, html-datasheet, General Product Information, Distributor-
Stock-Check, Detailed request for product
Technical Data
Rated voltage
Voltage Time Integral
Pulse Rise Time
Turns Ratio
Terminal Type
Weight
Material: Housing
Sealing Compound
up to 500 VAC
200 - 500 Vµs
0.5 - 1.5 µs
1:1, 1:1:1, 3:1:1
THT
7 - 15 g
UL 94V-0
UL 94V-0
Climatic Category
Allowable Operation Temp.
25/100/21 acc. to IEC 60068-1
-25 °C to 70 °C
Approvals and Compliances
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about
Approvals
Application standards
Application standards where the product can be used
Organization
Design
Designed for applications acc.
Standard
IEC/UL 60950
Description
IEC 60950-1 includes the basic requirements for the safety of information
technologyequipment.
Compliances
The product complies with following Guide Lines
Identification
Details
RoHS
China RoHS
REACH
Initiator
SCHURTER AG
SCHURTER AG
SCHURTER AG
Description
EU Directive RoHS 2011/65/EU
The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March
2007. It is similar to the EU directive RoHS.
On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration,
Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as
"REACH") entered into force.
EMC Products
1
IL
Dimension [mm]
Case 14-8
max. 28
20
max. 23
max. 14.5
(0.5)
max. 23
7.5
1)
15
0.5x0.5
https://www.schurter.com /PG85
Pulse Transformers
Case 14-9
max. 28
20
max. 14.5
(0.5)
1)
0.5x0.5
(0.4)
Housings
05-7
05-7
14-9
05-8
05-8
14-8
05-8
Ø
0.5
min. 5
1) Prim.
min. 5
Case 05-7
max. 17.5
12.5
max. 18.5
15
max. 11.5
(0.4)
Case 05-8
max. 17.5
5 7.5
max. 18.5
max. 11.5
Ø
0.5
15
1)
1) Prim.
min. 5
1) Prim.
1)
min. 5
All Variants
Turns Ratio
1:1
1:1
1:1
1:1:1
1:1:1
1:1:1
3:1:1
T
r
[μs]
1
1
1
0.5
1
1.5
0.7
I
ign
[A]
0.1
0.25
0.25
0.1
0.25
0.25
0.1
U
VAC
[V]
500
500
380
380
380
380
380
U
isol
[kV]
3.5
3.5
4.0
3.5
3.5
4.0
3.5
U
s
x T
w
[Vμs]
500
250
300
250
200
300
200
L
s
[mH]
8.0
2.5
3.0
2.5
1.5
3.0
16.5
R
P
[Ω]
1.2
0.6
0.6
0.6
0.4
0.6
2.3
R
S
[Ω]
1.2
0.6
0.6
0.6
0.4
0.6
0.5
C
C
[pF]
10
8
8
10
8
8
10
P
m
[W]
0.5
0.5
1.1
0.5
0.5
1.1
0.5
Weight [g]
7g
7g
15 g
7g
7g
15 g
7g
Packing unit [pcs.]
50
50
50
50
50
50
50
Order Number
IL-11-0001
IL-11-0002
IL-21-0001
IL-10-0001
IL-10-0003
IL-20-0001
IL-10-0002
█
█
█
█
Most Popular.
Availability for all products can be searched real-time:https://www.schurter.com/en/Stock-Check/Stock-Check-SCHURTER
2
EMC Products
The specifications, descriptions and illustrations indicated in this document are based on current
information. All content is subject to modifications and amendments. Information furnished is believed
to be accurate and reliable. However, users should independently evaluate the suitability and test each
product selected for their own applications.
24.11.2017
