Material
Plating
Wire Size
Wire Type
High Conductivity
Seamless Copper Tube
Electro-Tin
1/0 STR/FLEX
.45 R Ref
PANDUIT
Stranded Copper: Class B & C,
Compact, Class G, H, I, K, M,
Locomotive
1-9/16 in.
3/8 in.
Yes, for applications up to 35kv.
Consult cable manufacturer for
voltage stress relief instructions
with applications greater than
2000 volts.
90 C
Yes
PINK
.85±.04
Wire Strip Length
Stud Size
UL Listed Wire
Connector
1/0 STR/FLEX
LCCX1/0-38DH
PANDUIT
PINK DIE P42 (12)
.39±.04
1.00±.02
.41±.02 DIA
(2) PLS
Color coded
barrel markings
UL Temperature
Rating
C.S.A Certified
Wire Connector
Panduit Color Code
on Barrel
Beveled wire entry
.58±.01
.45±.01
1.50±.04
Panduit Die Index No. P42
on Barrel
Alternate Industry
Die Index No. ( )
on Barrel
(12)
Wire inspection window
45°±5°
1.78 REF
CERTIFIED
LISTED
Wire Connector
.13±.01
3.20 REF
CORP.
00
REV
TINLEY PARK, ILLINOIS
6/03
DATE
SAC SAC
BY
CHK
RELEASED
DESCRIPTION
10850
ECN
LCCX1/0-38DH-X
Copper Lug - Two-Hole, Long Flex Barrel with Window, 45° Angle Tongue
SCALE
N/A
DRAWING NO / CAD FILE
LCCX1_0-38DH-CUST
