This document was generated on 03/01/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0349004126
Active
MXP120 Sealed Connector System
MXP120 Sealed Receptacle, 4 Circuit, Black Housing with Long Shroud (T3-V2-S3 /
T4-V4-S3 with Backshell, T3-V2-S2 / T4-V4-S2 without Backshell), Key G, Light Gray
Insert
Documents:
3D Model
Drawing (PDF)
Product Specification PS-34900-0001-001 (PDF)
Application Specification AS-34900-0001-001 (PDF)
General
Product Family
Series
Application
Application Tooling Part Link
Comments
Overview
Polarization
Product Literature Order No
Product Name
UPC
Physical
Circuits (maximum)
Color - Resin
Gender
Glow-Wire Capable
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Material Info
Reference - Drawing Numbers
Application Specification
Packaging Specification
Product Specification
Sales Drawing
Application Specification AS-34900-0001-CH-001
(PDF)
Packaging Specification PK-31301-898-001 (PDF)
RoHS Certificate of Compliance (PDF)
Product Literature (PDF)
Series image - Reference only
EU ELV
Compliant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Relevant
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Relevant
Compliant
Not Contained
Crimp Housings
34900
Body Electronics, Power Train, Sealed, Wire-to-Wire
63824-6300
See sales drawing for terminal information.
MXP120 Sealed Connector System
G
987650-7994
MXP120 Sealed
889056197908
4
Black
Receptacle
No
Yes
Yes
SPS/Nylon
4.805/g
1
Bag
No
4.00mm
4.00mm
Yes
-40°C to +125°C
13.0A
Search Parts in this Series
34900 Series
Mates With
MXP120 Male Blade Connector 34899
Use With
MXP120 Backshell 160091-4020 ,
160091-4120 , 160091-4220 <br>MXP120
Cavity Plug 34996-1501 <br>MXP120
Cavity Plug Seal 34996-1902 <br>1.2 LL
SWS from Tyco and Kostal
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
AS-34900-0001-001, AS-34900-0001-CH-001
PK-31301-898-001
PS-34900-0001-001
SD-34900-2001-001, SD-34900-6001
